GE IC670ALG310 電壓源模擬輸出模塊
1.產 品 資 料 介 紹：
中文資料：
GE IC670ALG310 電壓源模擬輸出模塊的產品特點包括：
- 具有8個模擬通道，可以輸出電壓范圍從-10V到+10V，分辨率為14位。
- 用戶可配置的縮放比例，支持8個通道的輸出電壓，范圍從-10V到+10V，分辨率為14位。
- 輸出超范圍高達約10.25V。
- 可現場重新校準或重置為出廠校準，所有校準數據存儲在閃存中。
- 具有報告低于/超出范圍故障的功能。
- 在操作期間從總線接口接收工程單元輸出數據（BIU），并根據其校準和配置的縮放參數來縮放該數據，然后將數據轉換為-10V至+10V范圍內的輸出電壓。
- 如果主機發送的工程單位值導致輸出值約為模塊最大值或最小值的50mV，它將超出/低于范圍，并將設置一位報警位。
英文資料：
The product features of GE IC670ALG310 voltage source analog output module include:
It has 8 analog channels and can output voltage ranging from -10V to+10V, with a resolution of 14 bits.
User configurable scaling ratio, supporting 8 channels of output voltage, ranging from -10V to+10V, with a resolution of 14 bits.
The output exceeds the range by about 10.25V.
Can be recalibrated on-site or reset to factory calibration, and all calibration data is stored in flash memory.
It has the function of reporting faults below/beyond the range.
During operation, receive engineering unit output data (BIU) from the bus interface, scale the data according to its calibration and configured scaling parameters, and then convert the data into output voltage within the range of -10V to+10V.
If the engineering unit value sent by the host causes the output value to be approximately 50mV of the module's maximum or minimum value, it will exceed/fall below the range and an alarm bit will be set.
2.產 品 展 示
3.主 營 品 牌
4.產 品 展 示
ASML 4022.668.72021 高功率驅動器
ASML 4022.471.6850 Printed Circuit Board
ASML 4022.435.24401 Crystal Table Proces
| SR3624-4991 | AMAT 0100-90095 | DSDI451 ABB |
| SRF3736-4983-84-5-56BC-CU | AMAT 0100-76295 | DSDI452 ABB |
| SR3632-2094-48B | AMAT 0100-35066 | 57160001-NF DSDO115 ABB |
| SRF3643-4593-7-56C | AMAT 0100-35414 | 57160001-AK DSDO120 ABB |
| STF3758-5150-61-56BC | AMAT 0100-76109 | 5716075-K DSDX451 ABB |
