實時數據原則上只在子系統網絡(luò )節中點共享，跨域數據需要事先合理配置
實時數據泛指動態位號數據、各類報警和事件等由DCS控制器產生的實時數據和事件。大多數DCS應用情況中，操作站（操作員）只關心本域（子工程）內的實時數據，并對其進行及時和必要的處理。而對上下游的關聯裝置、公用工程，WOODWARD 8402-119伺服執行器只需要查看部分接口界面數據即可。
以上描述的實際應用情況大大降低了構建大型實時數據網絡(luò )實際負荷，這意味著大型DCS系統可以事先根據應用需求，拆分成若干個規模合理的子工程LAN。子工程數據庫相互獨立，通過事先的組態和配置，實現各子工程之間的數據交互，以及定期向管理層發送事先訂閱的各類實時數據。
中控WebField ECS-700系統基于以太網的IEEE802.3Z實現對數據流的分區管理，應用組播管理和VLAN等成熟網絡(luò )技術，使得邏輯子工程內的網絡(luò )節點共享數據，同時隔斷子工程間無用的實時數據，防止網絡(luò )上出現數據泛濫，導致傳輸效率下降甚至網絡(luò )阻塞。
2.2 完善的網絡(luò )監控和在線防病毒方案
大型DCS系統的網絡(luò )故障案例大多數定性為工程階段的問題，有工程設計的不合理、網絡(luò )部件的版本不兼容、工程實施時網線錯誤連接等。最常見的是網絡(luò )中毒，幾乎在所有的項目中都會(huì )發現各種級別的中毒情況，用傳統的病毒查殺技術費時費力，同時也會(huì )在一定程度上影響生產運行，更嚴重的甚至被迫停車檢修。WOODWARD 8402-119伺服執行器,8402-119說明書因此，DCS制造商在設計大型工業控制網絡(luò )時，必須考慮完整全面的網絡(luò )監控和防毒方案。
中控在該項目中提供了全網診斷軟件VxNetSight，該軟件可實時觀測到每個網段，甚至每個網口上的數據負荷，以及各個節點的上線、故障、恢復情況，可以方便地設置各種負荷報警和流控限制，協助用戶正確高效地了解網絡(luò )運行情況，并及時采取相應的管理措施。
migration path and protects users' investment in I / O and application development.
3. Solutions and main products of PAC control technology
From the definition, we can see that PAC is actually a systematic concept. It includes two parts: integrated software platform and hardware platform based on open modular structure. The solution of PAC technology also focuses on these two aspects.
Generally speaking, there are two ways to provide PAC software: Software Based on PLC control and software based on PC control.
1) Software scheme based on PLC control. Most PLC manufacturers build PAC software by adding new functions to the existing scanning architecture. These new functions include Ethernet communication, motion control and advanced algorithms. Usually, they will retain the familiar programming mode of PLC and the inherent characteristics in logic and control. Therefore, this kind of PAC software is usually designed for special types of applications.
