如果模塊安裝在帶有安全柵端子的輸入/輸出接線板上，則輔助端子
接線板可用于提供額外的接線端子。對于帶導線的輸入/輸出接線板
板連接器、外部連接點通常是首選，盡管是輔助連接點ATLAS TC-4000-P-PB-ES
可使用接線板。
輔助接線板的所有端子內部連接在一起。輔助設備
帶箱式端子的接線板有13個端子；每個可容納一個AWG#14（平均
2.1mm2ATLAS TC-4000-P-PB-ES溫度模塊
橫截面）至AWG#22（平均0.36mm2
橫截面）導線，或AWG以下的兩根導線
#18（平均0.86mm2
橫截面）。帶隔離柵端子的輔助接線板有九個
終端；每根電纜可容納一條或兩根AWG#14（平均2.1mm2）以下的電線
橫截面）。
下圖顯示了帶接線盒端子的可選輔助接線板
在帶接線盒的輸入/輸出接線板上安裝此模塊時，可用于電源連接
終端。
Wiring Examples with Auxiliary Terminal Blocks
If the module is installed on an I/O Terminal Block with Barrier Terminals, an Auxiliary Terminal
Block can be used to provide additional wiring terminals. For the I/O Terminal Block with Wire to
Board Connectors, external connection points are usually preferred, although an Auxiliary
Terminal Block can be used.
Auxiliary Terminal Blocks have all terminals connected together internally. The Auxiliary
Terminal Block with box terminals has 13 terminals; each accommodates one AWG #14 (avg
2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire, or two wires up to AWG
#18 (avg. 0.86mm2 cross section). The Auxiliary Terminal Block with barrier terminals has nine
terminals; each can accommodate one or two wires up to AWG #14 (avg 2.1mm2 cross section).
The following illustration shows how an optional Auxiliary Terminal Block with Box Terminals
can be used for power connections when installing this module on an I/O Terminal Block with Box
Terminals.
