TRICONEX CM2201底座,CM2201卡件
Hiway接口模塊
4509型Hiway接口
模塊（HIM）用作接口
Tricon控制器和霍尼韋爾TDC-3000控制系統
通過Hiway網關和本地控制網絡(luò )（LCN）。這個
HIM還可以與Honey well較舊的TDC 2000控制系統連接
通過數據通道。CM2201
HIM支持高階設備
在LCN或數據通道上，例如計算機和操作員工作站，
與Tricon通信。
HIM允許冗余BNC
直接連接到數據通道TRICONEX CM2201
并具有與
四個擴展數據通道端口（DHP）
地址。
HIM提供八個Hiway
地址，實現相同的插槽
結構為DHP，通常
刷新小于0.5的所有數據
秒。熱備盤功能
允許在線更換故障
單元
Hiway Interface Module
The Model 4509 Hiway Interface
Module (HIM) acts as an interface
between a Tricon controller and a
Honeywell TDC-3000 control system
by means of the Hiway Gateway and
Local Control Network (LCN). The
HIM can also interface with Honey
well’s older TDC 2000 control system
by means of the Data Hiway.
The HIM enables higher-order devices
on the LCN or Data Hiway, such as
computers and operator workstations,
to communicate with the Tricon.
The HIM allows redundant BNC
connections directly to the Data Hiway
and has the same functional capacity as
four extended Data Hiway Port (DHP)
addresses.
The HIM provides eight Hiway
addresses, implements the same slot
structure as the DHP, and typically
refreshes all data in less than 0.5
seconds. The hot-spare capability
allows online replacement of a faulty
module.
