TRICONEX DO3401控制卡件,DO3401使用配置教程
脈沖輸入模塊
3511型脈沖輸入（PI）
模塊提供八個非常敏感的，O3401
高頻輸入。它已優化
用于非放大磁性
轉速傳感器旋轉時共用
渦輪機或壓縮機等設備。模塊感應來自磁傳感器輸入的電壓傳輸
設備，在
選定的時間窗口（速率度量）。結果計數用于
生成一個頻率或RPM
傳輸到主處理器。這個
脈沖計數的測量分辨率為1微秒。
PI模塊包括三個隔離的
輸入通道。每個輸入通道
獨立處理所有數據輸入TRICONEX DO3401控制卡件
并將數據傳遞給
主處理器，對
確保最高完整性的數據。
每個模塊提供完整的
每個通道上的持續診斷。
任何診斷失敗
通道激活故障指示燈，
從而激活機箱
報警信號。故障指示燈
僅表示通道故障，而不是
模塊故障。模塊安裝有三通，可在現場正常運行
并可能繼續
使用某些類型的
多個故障。脈沖輸入模塊
支持熱備盤模塊。
Pulse Input Module
The Model 3511 Pulse Input (PI)
Module provides eight very sensitive,
high-frequency inputs. It is optimized
for use with non-amplified magnetic
speed sensors common on rotating
equipment such as turbines or compres
sors. The module senses voltage transi
tions from magnetic transducer input
devices, accumulating them during a
selected window of time (rate measure
ment). The resulting count is used to
generate a frequency or RPM which is
transmitted to the Main Processors. The
pulse count is measured to 1 micro
second resolution.
The PI module includes three isolated
input channels. Each input channel
independently processes all data input
to the module and passes the data to the
Main Processors, which vote on the
data to ensure the highest integrity.
Each module provides complete
ongoing diagnostics on each channel.
Failure of any diagnostic on any
channel activates the Fault indicator,
which in turn activates the chassis
alarm signal. The Fault indicator
merely indicates a channel fault, not a
module failure. The module is guaran
teed to operate properly in the presence
of a single fault and may continue to
operate properly with certain kinds of
multiple faults. The Pulse Input Module
supports hot- spare modules.
