TRICONEX MP3101冗余模塊,MP3101卡件
脈沖累加器輸入模塊
3515型脈沖累加器輸入
（PTI）模塊提供32個MP3101
獨立運行的31位計數器。計數器用于
主動式流量傳感器或每單位傳感器
測量以下數量（計數）：
傳輸到主處理器。在
控件指定的時間
程序，主處理器清除
單個計數器或所有計數器。
PTI模塊有三個隔離輸入
頻道。每個輸入通道獨立地處理所有輸入數據和
將其傳遞到主處理器，其中
在處理之前進行投票，以確保
最高誠信。
每個PTI模塊提供完整的
每個通道上的持續診斷，
包括通道到通道計數
比較任何診斷故障TRICONEX MP3101冗余模塊,MP3101卡件
在任何通道上，激活故障指示器，進而激活
底盤警報。故障指示燈
指向通道故障，而不是模塊
失敗PTI模塊得到保證
在有
單一故障，并可能繼續
使用某些類型的多個
故障。
PTI模塊可與或一起工作
沒有熱備盤模塊。如果您使用
一個熱備盤模塊，可重新教育所有
來自激活模塊的計數器值。
Pulse Totalizer Input Module
The Model 3515 Pulse Totalizer Input
(PTI) Module provides 32 individual
31-bit counters that operate indepen
dently. The counters are used with
active-flow sensors or per-unit sensors
to measure a quantity (count) which is
transmitted to the Main Processors. At
the time specified by the control
program, the Main Processors clear a
single counter or all counters.
The PTI module has three isolated input
channels. Each input channel indepen
dently processes all input data and
passes it to the Main Processors, where
it is voted before processing to ensure
the highest integrity.
Each PTI module provides complete
ongoing diagnostics on each channel,
including channel-to-channel count
comparison. Failure of any diagnostic
on any channel activates the Fault indi
cator, which in turn activates the
chassis alarm. The Fault indicator
points to a channel fault, not a module
failure. The PTI module is guaranteed
to operate properly in the presence of a
single fault, and may continue to
operate with certain kinds of multiple
faults.
The PTI module can operate with or
without a hot-spare module. If you use
a hot-spare module, it re-educates all
counter values from the active module.
