TRICONEX 3625卡件,TRICONEX 3625使用范圍
UMT 1是一個測量傳感器，用于RMS值。UMT 1可以測量
帶電流和電壓測量輸入。主要計算并顯示測量值在雙線16字符LC顯示屏上，以及也可通過模擬輸出傳輸
（可配置為-20至20 mA、0至20 mA或4至20 mA）或至高級控制系統。
電壓和電流用于計算實際功率、無功功率和視在功率、功率系數、kWh和kvarh。kWh和
kVarh也可以通過使用脈沖輸出。
TRICONEX 3625卡件測量值列表包括測量的o電壓§Y形三通：VL1N/VL2N/VL3N
§Delta：VL12/VL23/VL31 o頻率fL123
o電流IL1/IL2/IL3·已計算
o平均電壓V?L123/Vmin/Vmax
o平均電流I?L123/Imin/Imax
o實際功率PTotal/PL1/PL2/PL3
o無功功率總量
o視在功率Stotal
o功率因數cosφL1
TRICONEX 3625卡件o有功電能kWh正/負
o無功能量kvarhleading/laging
無法通過PC進行遠程配置說明：有不同的UMT 1包
從中選擇：組件UMT 1/A3·3×真RMS電壓傳感
·3×真RMS電流感應
·0.5級精度
·3配置。模擬輸出（20 mA）
·1配置。千瓦時/千瓦時的脈沖輸出
·雙線LC顯示器
組件UMT 1/A3SU·3×真RMS電壓傳感
·3×真RMS電流感應·0.5級精度
·3配置。模擬輸出（20 mA）
·1配置。千瓦時/千瓦時的脈沖輸出
·雙線LC顯示器
·RS-485/Modbus RTU
組件UMT 1/A6·3×真RMS電壓傳感
·3×真RMS電流感應·0.5級精度
·6配置。模擬輸出（20 mA）
·1配置。千瓦時/千瓦時的脈沖輸出
·雙線LC顯示器
·真RMS感應·0.5級精度
·顯示的所有值在LCD上并通過20 mA模擬輸出
·前面板可配置1）·微處理器技術用于準確、可重復而且可靠活動·可選接線的配置
單相，三相，或a兩者的結合
·RS-485 Modbus
RTU從機表達UL/cUL列出·CE標記
The UMT 1 is a measuring transducer for true
RMS values. The UMT 1 can measure an
electrical three-phase system with current and
voltage measuring inputs. The primary
measured values are calculated and displayed
on the two-line, 16 character LC Display, and
also transmitted by either analog outputs
(configurable as -20 to 20 mA, 0 to 20 mA, or 4
to 20 mA) or a communication interface to a
higher level-control system.
The primary measured values of voltage and
current are used to calculate the values for
real, reactive, and apparent power, power
factor (cosphi), kWh, and kvarh. The kWh and
kVarh can also be transmitted by using an
pulse output.
The list of measured values includes
· Measured
o Voltage
§
Wye: V
L1N / VL2N / VL3N
§ Delta: VL12 / VL23 / VL31
o Frequency fL123
o Current IL1/IL2/IL3
· Calculated
o
Average voltage V?L123 / Vmin / Vmax
o
Average curren
t I
?L123
/ I
min
/ I
max
o
Real power PTotal
/ PL1
/ P
L2
/ P
L3
o
Reactive power Q
total
o
Apparent power S
total
o
Power factor cosφ
L1
o
Active energy kWh
positive/negative
o
Reactive energy kvarhleading/lagging
1) Remote configuration via PC is not available
DE
SCRIPTION
There are different UMT 1 packages to
choose from:
Package UMT 1/A3
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 3 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
Package UMT 1/A3SU
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 3 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
· RS-485/Modbus RTU
Package UMT 1/A6
· 3× true RMS voltage sensing
· 3× true RMS current sensing
· Class 0.5 accuracy
· 6 config. analog outputs (20 mA)
· 1 config. pulse output for kWh/kvarh
· Two-line LC display
·
True RMS sensing
·
Class 0.5 accuracy
·
All values displayed
on LCD and through
20 mA analog output
·
Front panel
configurable1)
·
Microprocessor
technology for
accurate, repeatable
and reliable
operation
·
Optional wiring
configurations for
either single phase,
three phase, or a
combination of both
·
RS-485 Modbus
RTU Slave
communication
·
UL/cUL Listed
·
CE marked
