NI SCXI-1141 182610D-01工控控制卡件模塊
1.產 品 資 料 介 紹：
中文資料：
NI SCXI-1141 是國家儀器（National Instruments, NI）生產的一款模擬輸出/數字輸入模塊，專為工業控制和測量應用設計。以下是關于 NI SCXI-1141 工控控制卡件模塊的基本信息和特點：
基本信息
- 制造商: National Instruments (NI)
- 型號: SCXI-1141
- 產品代碼: 182610D-01
主要特點
模擬輸出通道:
- 4路模擬輸出: 提供4個獨立的模擬輸出通道，每個通道可以輸出可調節的模擬電壓信號。
數字輸入通道:
- 32路數字輸入: 提供32個獨立的數字輸入通道，用于讀取和監測數字信號。
信號類型:
- 模擬輸出: 可以輸出穩定的模擬電壓信號，用于控制外部設備或模擬輸出測試。
- 數字輸入: 用于監測數字信號狀態，如開關、傳感器等。
精確度和穩定性:
- 高分辨率: 提供高分辨率的模擬輸出，確保精確的電壓控制和測量。
- 穩定性: 具備良好的溫度穩定性和長時間運行穩定性，適用于工業控制環境。
軟件支持:
- LabVIEW: 兼容NI LabVIEW軟件，提供強大的數據采集、控制和分析功能。
- SCXI驅動程序: 支持NI的SCXI模塊驅動程序，簡化配置和編程過程。
模塊化設計:
- SCXI接口: 設計用于NI SCXI模塊化測量系統，便于與其他SCXI模塊集成，構建多功能測試和控制系統。
應用領域:
- 工業控制: 在工業自動化系統中用于模擬信號輸出和數字信號監測。
- 測試和測量: 用于實驗室測試和測量中的模擬輸出和數字輸入應用。
- 數據采集: 用于數據采集系統中的控制和信號處理。
總結
NI SCXI-1141 工控控制卡件模塊是一款多功能的模擬輸出/數字輸入設備，適用于工業控制和實驗室測量應用。通過其模擬輸出和數字輸入的組合，能夠滿足復雜的控制和數據采集需求。其與NI LabVIEW和SCXI驅動程序的無縫集成，使其成為工業自動化、測試和測量以及數據采集系統中的理想選擇
英文資料
NI SCXI-1141 is an analog output/digital input module produced by National Instruments (NI), designed specifically for industrial control and measurement applications. The following is the basic information and characteristics of the NI SCXI-1141 industrial control card module:
Basic information
Manufacturer: National Instruments (NI)
Model: SCXI-1141
Product code: 182610D-01
main features
Analog output channel:
4 analog outputs: Provide 4 independent analog output channels, each channel can output adjustable analog voltage signals.
Digital input channel:
32 digital inputs: Provides 32 independent digital input channels for reading and monitoring digital signals.
Signal type:
Analog output: It can output stable analog voltage signals for controlling external devices or analog output testing.
Digital input: used to monitor the status of digital signals, such as switches, sensors, etc.
Accuracy and stability:
High resolution: Provides high-resolution analog output to ensure precise voltage control and measurement.
Stability: It has good temperature stability and long-term operation stability, suitable for industrial control environments.
Software support:
LabVIEW: Compatible with NI LabVIEW software, providing powerful data collection, control, and analysis functions.
SCXI driver: SCXI module driver that supports NI, simplifying configuration and programming processes.
Modular design:
SCXI interface: designed for NI SCXI modular measurement system, facilitating integration with other SCXI modules, and building a multifunctional testing and control system.
Application field:
Industrial control: used in industrial automation systems for analog signal output and digital signal monitoring.
Testing and measurement: Used for analog output and digital input applications in laboratory testing and measurement.
Data acquisition: used for control and signal processing in data acquisition systems.
summary
The NI SCXI-1141 Industrial Control Card Module is a multifunctional analog output/digital input device suitable for industrial control and laboratory measurement applications. By combining its analog output and digital input, it can meet complex control and data acquisition needs. Its seamless integration with NI LabVIEW and SCXI drivers makes it an ideal choice for industrial automation, testing and measurement, and data acquisition systems
2.產 品 展 示
3.產 品 展 示
