Configuring Through PlantScape Control Builder
If you are using the PlantScape System, perform the following steps to configure the
SST-PB3-CLX-RLL scanner:
1. Open the PlantScape Control Builder by navigating to Programs > PlantScape
Engineering Tools > Control Builder.
2. Close one of the project windows that displays.
3. Select CPM block.
4. Select the Load with Contents option from the Tools menu.
5. Select the Continue button.
6. Select the Monitoring tab located on the bottom of the Project window.
7. Select CEE.
8. From the Operate menu, select Activate.
9. From the sub-menu, select the This CEE and its 10M and CM's option.
10. Select YES in the Change State dialog box. This procedure places the processor in Run
mode and the SST-PB3-CLX-RLL scanner online and in Run mode. For detailed
information, refer to Honeywell's PlantScape PROFIBUS Implementation guide.The SST PROFIBUS Configuration Tool window consists of a main or Network view and two
panes: the PROFIBUS Devices pane (Device Library) and the Online Browse pane (DP view).
Both of these are floating panes; drag and drop them to move them anywhere inside the
Network view.
