12P3162X212串行鏈路模塊,12P3162X212使用數據
HSS模塊使用易受靜電放電影響的設備。遵循以下處理程序：
注意：始終使用Bailey的現場靜態套件（零件號1948385_1-由兩條腕帶、接地線組件、鱷魚夾、，和靜態耗散工作面）。
該套件使技師和靜電耗散工作面接地至同一接地點，以防止靜電放電損壞模塊。
1、使用靜電屏蔽袋。保持模塊處于靜態狀態屏蔽袋，直到您準備好將其安裝到系統中。保存袋子以備將來使用。
12P3162X212串行鏈路模塊2、打開前將袋子磨碎。在打開裝有半導體組件的袋子之前，將其觸摸到設備外殼或均衡電荷的接地。3、避免接觸電路。通過邊緣；避免接觸電路。4、避免半導體部分連接。驗證所有連接到模塊的設備都正確使用前接地。
5、地面測試設備。6、使用防靜電現場維修真空。清除灰塵如有必要，從模塊中刪除。
7、使用接地腕帶。將腕帶連接到電源輸入面板上的適當接地插頭。這個電源入口面板上的接地插頭必須有效通過連接至接地電極系統交流安全接地。
8、請勿使用鉛筆設置雙列直插式開關。避免雙列直插式開關觸點的污染可能導致
The HSS module uses devices susceptible to electrostatic dis
charge. Follow these handling procedures:
NOTE: Always use Bailey's field static kit (part number 1948385_1 -
consisting of two wrist straps, ground cord assembly, alligator clip,
and static dissipative work surface) when working with the modules.
The kit grounds a technician and the static dissipative work surface
to the same ground point to prevent damage to the modules by elec
trostatic discharge.
1. Use Static Shielding Bag. Keep the modules in the static
shielding bag until you are ready to install them in the system.
Save the bag for future use.
2. Ground Bag Before Opening. Before opening a bag con
taining an assembly with semiconductors, touch it to the
equipment housing or a ground to equalize charges.
3. Avoid Touching Circuitry. Handle assemblies by the
edges; avoid touching the circuitry.
4. Avoid Partial Connection of Semiconductors. Verify
that all devices connected to the modules are properly
grounded before using them.
5. Ground Test Equipment.
6. Use an Antistatic Field Service Vacuum. Remove dust
from the module if necessary.
7. Use a Grounded Wrist Strap. Connect the wrist strap to
the appropriate grounding plug on the power entry panel. The
grounding plug on the power entry panel must be effectively
connected to the earth grounding electrode system through the
AC safety ground.
8. Do Not Use Lead Pencils to Set Dipswitches. To avoid
contamination of dipswitch contacts that can result in
