VE3008控制卡件,VE3008使用方法
IMHSS03模塊使用一個NTHS03液壓伺服終端裝置來終止其輸入/輸出連接。DIP分流器和跳線選擇電源（系統電源或外部電源功率）。IMHSS03模塊有四個模擬輸入，九個模擬輸出，三個數字輸入和一個數字輸出終止于第n個03位終端裝置。
快速參考附錄C提供了NTHS03輸入/輸出終端分配、跳線和雙工分流設置、電路板的快速參考布局和電纜連接。參見液壓伺服有關更多信息，請參閱終端單元（NTHS03）說明。圖C-1顯示了NTHS03電路板布局。表C-1
VE3008控制卡件列出NTHS03跳線設置。表C-2列出了終端裝置雙分流設置。圖C-2顯示了終端分配和輸入/輸出信號極性。圖C-3顯示了終端裝置電纜連接。IMHSS03模塊可以使用NIDI01數字輸入/輸出終端模塊來終止其輸入/輸出連接。完整IMHSS03功能需要兩個帶有NKAS02的NIDI01模塊終端電纜。一個NIDI01模塊可以終止IMHSS03模塊，但僅提供IMHSS02功能。終端模塊上的跳線配置輸入/輸出信號。IMHSS03模塊有四個模擬輸入、九個模擬輸出、三個數字輸入和一個終止的數字輸出在NIDI01終端模塊。
The IMHSS03 module uses an NTHS03 Hydraulic Servo Termination Unit to terminate its I/O connections. Dipshunts and
jumpers select the power source (system power or external
power) for certain inputs and outputs. The IMHSS03 module
has four analog inputs, nine analog outputs, three digital
inputs and one digital output that terminate at the NTHS03
termination unit.
QUICK REFERENCE
Appendix C serves as a quick reference of NTHS03 I/O terminal assignments, jumper and dipshunt settings, circuit board
layout and cable connections. Refer to the Hydraulic Servo
Termination Unit (NTHS03) instruction for more information.
Figure C-1 shows the NTHS03 circuit board layout. Table C-1
lists NTHS03 jumper settings. Table C-2 lists the terminationunit dipshunt settings. Figure C-2 shows terminal assignments and I/O signal polarity. Figure C-3 shows the termination unit cable connection.The IMHSS03 module can use an NIDI01 Digital I/O Termination Module to terminate its I/O connections. Full IMHSS03
functionality requires two NIDI01 modules with an NKAS02
termination cable. One NIDI01 module can terminate the
IMHSS03 module, but will only provide IMHSS02 functionality.
Jumpers on the termination module configure the I/O signals.
The IMHSS03 module has four analog inputs, nine analog outputs, three digital inputs and one digital output that terminate
at the NIDI01 termination module.
