REXROTH PPC-R22.1N-N-Q1-NN-NN-FW 伺服驅動器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
REXROTH PPC-R22.1N-N-Q1-NN-NN-FW 是一款高性能的數字控制器，專為復雜的運動控制和自動化應用而設計。它集成了強大的處理能力和靈活的編程接口，能夠滿足多軸運動控制系統的需求。以下是該數字控制器的主要特點和技術規格：
主要特點：
多軸運動控制：
- 支持多軸同步控制，能夠協調多個伺服電機的運動，適用于復雜的自動化任務。
高性能處理器：
- 內置高性能的處理器，能夠快速執行復雜的控制算法，確保系統的高動態響應和精確控制。
豐富的通訊接口：
- 配備多種工業通訊接口，包括 EtherCAT、PROFIBUS、CANopen 等，便于與其他控制設備和系統進行無縫集成。
靈活的編程環境：
- 支持標準的編程語言和開發環境，如 IEC 61131-3 標準的 PLC 編程，便于用戶根據應用需求進行定制化編程。
內置運動功能庫：
- 提供豐富的運動控制功能庫，包括電子齒輪、電子凸輪、插補運動等，簡化了復雜運動控制的實現。
模塊化設計：
- 設計為模塊化結構，便于擴展和升級，能夠靈活適應不同應用場景的需求。
安全功能：
- 集成安全功能，如安全扭矩關閉（STO），為工業自動化系統提供高水平的安全保護。
技術規格：
- 型號：PPC-R22.1N-N-Q1-NN-NN-FW
- 處理器：高性能的多核處理器，支持快速數據處理和實時控制
- 控制軸數：支持多軸控制，具體軸數取決于配置和應用需求
- 通訊接口：EtherCAT、PROFIBUS、CANopen 等多種接口，支持靈活的系統集成
- 編程環境：支持 IEC 61131-3 標準的編程語言，如梯形圖（LD）、功能塊圖（FBD）、結構化文本（ST）
- 電源要求：適用于工業標準的電源輸入（具體電壓規格需參考產品手冊）
- 安裝方式：DIN 導軌或面板安裝，適合集成在控制柜或機器面板中
- 操作系統：內置實時操作系統，支持復雜控制任務的調度和管理
英文資料：
REXROTH PPC-R22.1N-N-Q1-NN-NN-FW is a high-performance digital controller designed specifically for complex motion control and automation applications. It integrates powerful processing capabilities and flexible programming interfaces to meet the needs of multi axis motion control systems. The following are the main features and technical specifications of the digital controller:
Main features:
Multi axis motion control:
Support multi axis synchronous control, able to coordinate the motion of multiple servo motors, suitable for complex automation tasks.
High performance processor:
Equipped with a high-performance processor, it can quickly execute complex control algorithms, ensuring high dynamic response and precise control of the system.
Rich communication interfaces:
Equipped with multiple industrial communication interfaces, including EtherCAT, PROFIBUS, CANopen, etc., for seamless integration with other control devices and systems.
Flexible programming environment:
Supports standard programming languages and development environments, such as IEC 61131-3 standard PLC programming, making it easy for users to customize programming according to application needs.
Built in sports function library:
Providing a rich library of motion control functions, including electronic gears, electronic camshafts, interpolation motion, etc., simplifies the implementation of complex motion control.
Modular design:
Designed as a modular structure, it is easy to expand and upgrade, and can flexibly adapt to the needs of different application scenarios.
Security function:
Integrated safety features, such as Safety Torque Off (STO), provide high-level safety protection for industrial automation systems.
Technical specifications:
Model: PPC-R22.1N-N-Q1-NN-NN-FW
Processor: High performance multi-core processor that supports fast data processing and real-time control
Number of control axes: Supports multi axis control, the specific number of axes depends on the configuration and application requirements
Communication interface: EtherCAT, PROFIBUS, CANopen and other multiple interfaces, supporting flexible system integration
Programming environment: Supports programming languages that comply with the IEC 61131-3 standard, such as ladder diagrams (LD), functional block diagrams (FBD), and structured text (ST)
Power requirements: Suitable for industrial standard power input (specific voltage specifications should refer to the product manual)
Installation method: DIN rail or panel installation, suitable for integration into control cabinets or machine panels
Operating System: Built in real-time operating system, supporting scheduling and management of complex control tasks
2.產 品 展 示
