REXROTH CSB01.1N-PB-ENS-NNN-NN-S-NN-FW伺服控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
關于REXROTH CSB01.1N-PB-ENS-NNN-NN-S-NN-FW伺服控制器，以下是詳細的信息概述：
一、基本信息
- 型號：CSB01.1N-PB-ENS-NNN-NN-S-NN-FW
- 品牌：Bosch Rexroth（力士樂(lè )）
- 產地：德國
二、產品特性
- 控制核心：采用數字信號處理器(DSP)作為控制核心，能夠執行位置、速度、轉矩和電流控制器的功能，實現比較復雜的控制計算。
- 驅動電路：功率器件普遍采用以智能功率模塊(IPM)為核心設計的驅動電路，內部集成了驅動電路，并具有過電壓、過電流、過熱、欠壓等故障檢測保護電路。
- 逆變技術：通過整流部分將交流電源變?yōu)橹绷麟娫?，再由逆變部分將直流電源轉變?yōu)镾PWM波形，以驅動伺服電機。
- 編碼器：伺服電機配有高性能的轉角測量編碼器，可以精確測量轉子的位置與電機的轉速。
三、接口與配置
- 通訊接口：支持多種通訊接口，如PROFIBUS總線（PB）、Sercos、EtherCAT等，便于與不同系統進行集成。
- 配置選項：
- ENS = 編碼器indraDyn / Hiperface / 1 Vss / TTL
- NNN = 不裝備（在某些選項位置）
- S = 標準控制面板
四、應用領域
- REXROTH CSB01.1N系列伺服控制器適用于多種工業自動化領域，如機床、生產線、機器人等，能夠滿足不同應用場景對運動控制的需求。
英文資料：
Regarding the REXROTH CSB01.1N-PB-ENS-NNN-NN-S-NN-FW servo controller, the following is a detailed overview of the information:
1、 Basic Information
Model: CSB01.1N-PB-ENS-NNN-NN-S-NN-FW
Brand: Bosch Rexroth
Origin: Germany
2、 Product Features
Control core: Using a digital signal processor (DSP) as the control core, it can perform the functions of position, speed, torque, and current controllers, and achieve complex control calculations.
Drive circuit: Power devices commonly use drive circuits designed with intelligent power modules (IPM) as the core, which integrate the drive circuit internally and have fault detection and protection circuits for overvoltage, overcurrent, overheating, undervoltage, etc.
Inverter technology: By rectifying the AC power supply into a DC power supply, the inverter converts the DC power supply into SPWM waveform to drive the servo motor.
Encoder: The servo motor is equipped with a high-performance angle measurement encoder, which can accurately measure the position of the rotor and the speed of the motor.
3、 Interface and Configuration
Communication interface: Supports multiple communication interfaces such as PROFIBUS bus (PB), Sercos, EtherCAT, etc., making it easy to integrate with different systems.
Configuration options:
ENS=Encoder indraDyn/Hiperface/1 VSS/TTL
NNN=Not equipped (in certain option positions)
S=Standard Control Panel
4、 Application Fields
The REXROTH CSB01.1N series servo controller is suitable for various industrial automation fields, such as machine tools, production lines, robots, etc., and can meet the needs of motion control in different application scenarios.
2.產 品 展 示
