EPRO PR6423/002-001-CN線纜前置器,PR6423/002-001-CN產品重量
電流和電壓輸出的連接。每個通道可以配置為作為電壓輸出或電流輸出-不能同時作為電壓輸出或電流輸出。發光二極管模塊OK LED指示模塊狀態。用戶電源LED指示是否外部+24存在VDC電源，并且高于最低水平。兩個LED均由+5 VDC供電背板電源總線。危險場所安裝? 標有I類A、B、C和D組2類危險品標簽的設備位置適合用于I類2類A、B、C、D組或非危險區域僅限位置? 警告-爆炸危險-更換部件可能會(huì )影響其適用性I類，2類；
EPRO PR6423/002-001-CN線纜前置器? 警告-爆炸危險-在危險位置時，在更換或接線模塊；和? 警告-爆炸危險-除非已通電，否則不要斷開設備關閉或該區域已知為非危險區域，這是本次發布的重要產品信息升級此固件升級僅適用于硬件版本為Bx的ALG392。ALG392模塊不能現場使用此固件版本升級。如果需要升級到固件版本1.60，則ALG392 Bx模塊必須返回工廠。兼容性90-30系列PLC CPU：對于CPU固件版本3.3至4.6，模塊必須配置為16%I輸入否則會(huì )出現模塊丟失故障。CPU固件必須為5.0或更高版本，才能為配置模塊8%I輸入。手持式編程器：只有90-30系列模塊IC693ALG392 C版或更早版本支持該系列90-30手持式編程器。90-30系列模塊IC693ALG392 BD或更高版本和RX3i模塊IC694ALG392（所有版本）不能與手持式編程器一起使用。
The diagram above shows connections for current and voltage outputs. Each channel can be configured to
operate as a voltage output or a current output - not both simultaneously.
LEDs
The Module OK LED indicates module status. The User Supply LED indicates whether the external +24
VDC power supply is present and is above the minimum level. Both LEDs are powered from the +5 VDC
backplane power bus.Installation in Hazardous Locations
? EQUIPMENT LABELED WITH REFERENCE TO CLASS I, GROUPS A, B, C & D, DIV. 2 HAZARDOUS
LOCATIONS IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C, D OR NON-HAZARDOUS
LOCATIONS ONLY
? WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR
CLASS I, DIVISION 2;
? WARNING - EXPLOSION HAZARD - WHEN IN HAZARDOUS LOCATIONS, TURN OFF POWER BEFORE
REPLACING OR WIRING MODULES; AND
? WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN
SWITCHED OFF OR THE AREA IS KNOWN TO BE NONHAZARDOUSImportant Product Information for this Release
Upgrades
This firmware upgrade applies only to ALG392 with hardware version –Bx. ALG392 modules cannot be
upgraded with this firmware release in the field. If an upgrade to firmware version 1.60 is required, the
ALG392-Bx module must be returned to the factory.
Compatibility
Series 90-30 PLC CPU: for CPU firmware versions 3.3 to 4.6, the module must be configured for 16 %I inputs
or a Loss of Module Fault will occur. CPU firmware must be version 5.0 or later to configure the module for
8% I inputs.
Hand-Held Programmer: Only Series 90-30 modules IC693ALG392 version C or earlier support the Series
90-30 Hand-held Programmer. Series 90-30 modules IC693ALG392 version BD or later and RX3i modules
