1398-DDM-075機器人數控模塊,1398-DDM-075使用配置教程
Genius總線控制器數量最多可包括八個Genius總線控制器或增強型Genius通信模塊在具有5.0版或更高版本CPU固件的Series 90-30 PLC系統中。GBC不能安裝在帶有GCM的系統中?？偩€(xiàn)上的輸入/輸出設備可以是Genius輸入/輸出塊，或一個或多個總線中的標準Series 90-70輸入/輸出模塊更多遠程下降。一條Genius總線可以服務的輸入/輸出電路的總數取決于CPU中使用的輸入/輸出設備類型和可用內存。
1398-DDM-075機器人數控模塊許多Genius輸入/輸出塊在同一塊上同時具有輸入和輸出。在中配置的塊具有輸入和輸出的編程軟件占用相同數量的引用在%I和%Q內存中，無論塊的軟件配置如何。未使用的引用不能分配給其他輸入或輸出，不應在應用程序中使用。狀態LEDGBC正面的LED指示其工作狀態，正常情況下應點亮活動OK顯示GBC模塊的狀態。通電診斷完成后，該LED點亮完整的。COM顯示Genius通信總線的狀態。當總線啟動時，該LED穩定亮起操作正常。對于間歇性總線錯誤，它會(huì )閃爍，對于發生故障的總線，它會(huì )關閉。它是當沒有從PLC CPU接收到配置時，也關閉。兼容性列出了與GBC模塊兼容所需的特定設備或軟件版本在下面90-30系列PLCCPU:GBC模塊可用于以下CPU型號：IC693CPU311K、321K、331L或更高版本，或IC693CPU313、323、340、341、350、351、352、360、363和364的任何版本。CPU固件必須是5.0版或更高版本。Logicmaster 90-30版本5.0（IC641SWP301L、304J、306F、307F）、VersaPro或需要Logic Developer PLC軟件。系列六PLC要與Genius總線控制器交換全局數據，系列6總線控制器
Number of Genius Bus Controllers
Up to eight Genius Bus Controllers or Enhanced Genius Communications Modules can be included
in a Series 90-30 PLC system that has release 5.0 or later CPU firmware. A GBC cannot be
installed in a system with a GCM.
The I/O devices on a bus may be Genius I/O blocks, or standard Series 90-70 I/O modules in one or
more remote drops. The total number of I/O circuits that can be served by one Genius bus depends
on the types of I/O devices that are used and the memory available in the CPU.
Many Genius I/O blocks have both inputs and outputs on the same block. Blocks configured in the
programming software as having both inputs and outputs occupy the identical number of references
in both %I and %Q memory, regardless of the block’s software configuration. Unused references
cannot be assigned to other inputs or outputs, and should not be used in the application program.
Status LEDs
The LEDs on the front of the GBC indicate its operating status and should be on during normal
operation.
OK Shows the status of the GBC module. This LED turns on after power up diagnostics are
completed.
COM Shows the status of the Genius communications bus. This LED is on steadily when the bus
is operating properly. It blinks for intermittent bus errors and is off for a failed bus. It is
also off when no configuration has been received from the PLC CPU.
Compatibility
Specific equipment or software versions required for compatibility with the GBC module are listed
below.
