TRICONEX 3201數字輸入單元 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX 3201 數字輸入單元 是 Triconex 控制系統中的一個重要模塊，專為接收來自外部設備的數字輸入信號并將其傳輸至主控制系統。以下是簡要的特點和應用：
主要特點：
- 數字輸入支持：接收來自傳感器、開關、按鈕等設備的數字信號（開/關狀態）。
- 高冗余設計：與 Triconex 系統的三重冗余（TMR）結構兼容，確保在部分模塊故障時系統仍能穩定運行。
- 高可靠性：設計用于高安全性應用，滿足 SIL3 安全標準，確保數字信號傳輸的準確性和穩定性。
- 模塊化設計：支持熱插拔功能，便于快速更換和維護，減少停機時間。
- 多通道支持：通常提供多個輸入通道，可同時接入多個設備，提升系統的擴展性。
應用領域：
- 安全儀表系統（SIS）：用于接收安全相關的數字輸入信號，執行緊急停機或其他安全控制。
- 過程控制系統：用于接收來自過程設備的狀態信號，如閥門開關、傳感器觸發等。
- 緊急停機系統（ESD）：用于監控外部設備的狀態，觸發緊急停機動作。
優勢：
- 高可靠性和安全性，符合 SIL3 標準，確保關鍵控制任務的穩定執行。
- 模塊化設計，支持熱插拔，便于快速維護和更換。
- 適應性強，能夠處理多個數字輸入信號，滿足復雜工業控制需求。
英文資料：
The Triconex 3201 digital input unit is an important module in the Triconex control system, designed to receive digital input signals from external devices and transmit them to the main control system. The following are brief characteristics and applications:
Main features:
Digital input support: Receive digital signals (on/off status) from sensors, switches, buttons, and other devices.
High redundancy design: Compatible with the Triple Redundancy (TMR) structure of the Triconex system, ensuring stable operation of the system even in the event of partial module failures.
High reliability: Designed for high security applications, meeting SIL3 safety standards to ensure the accuracy and stability of digital signal transmission.
Modular design: Supports hot swappable functionality for quick replacement and maintenance, reducing downtime.
Multi channel support: typically provides multiple input channels that can simultaneously connect multiple devices, enhancing the scalability of the system.
Application areas:
Safety Instrumented System (SIS): Used to receive safety related digital input signals, perform emergency shutdown or other safety controls.
Process control system: used to receive status signals from process equipment, such as valve switches, sensor triggers, etc.
Emergency Shutdown System (ESD): Used to monitor the status of external devices and trigger emergency shutdown actions.
Advantages:
High reliability and safety, compliant with SIL3 standards, ensuring stable execution of critical control tasks.
Modular design, supporting hot swapping, easy to maintain and replace quickly.
Strong adaptability, capable of processing multiple digital input signals, meeting complex industrial control requirements.
2.產 品 展 示
