ABB 1SAJ520000R0101 UMC100-FBP.0 A4 電機控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB 1SAJ520000R0101 UMC100-FBP.0 A4 電機控制器 是一款高度靈活且功能強大的通用電機控制器。它用于保護和控制低壓電機，并通過先進的通信接口實現集成化管理，廣泛應用于工業自動化、電機保護和控制領域。
產品概述
主要功能：
- 提供電機保護（如過載保護、短路保護、接地故障保護等）。
- 支持對電機啟動、運行、監控和停止進行全面控制。
- 集成通信功能，可與工業現場總線系統連接。
應用領域：
- 工業自動化生產線的電機控制與保護。
- 泵、風機和壓縮機等設備的運行管理。
- 配電柜和控制柜中的電機監控與控制。
技術參數
| 參數 | 描述 |
|---|---|
| 型號 | 1SAJ520000R0101 UMC100-FBP.0 A4 |
| 額定電壓 | 24-240 V AC/DC |
| 電流范圍 | 0.24 A 至 63 A |
| 工作溫度 | -25°C 至 +70°C |
| 通信接口 | FieldBusPlug（FBP）通信接口 |
| 支持協議 | Modbus、Profibus、Profinet、DeviceNet 等 |
| 安裝方式 | DIN 導軌安裝 |
| 輸入輸出 | 多達 6 個數字輸入，3 個數字輸出 |
| 保護功能 | 過載保護、短路保護、接地故障保護、堵轉保護 |
| 顯示方式 | 狀態 LED 或外接 HMI 顯示 |
| 防護等級 | IP20 |
英文資料：
The ABB 1SAJ520000R0101 UMC100-FBP. 0 A4 motor controller is a highly flexible and powerful universal motor controller. It is used to protect and control low-voltage motors, and achieves integrated management through advanced communication interfaces, widely used in industrial automation, motor protection, and control fields.
Product Overview
Main functions:
Provide motor protection (such as overload protection, short circuit protection, ground fault protection, etc.).
Support comprehensive control of motor start, operation, monitoring, and stop.
Integrated communication function, capable of connecting with industrial fieldbus systems.
Application areas:
Motor control and protection for industrial automation production lines.
Operation and management of equipment such as pumps, fans, and compressors.
Motor monitoring and control in distribution cabinets and control cabinets.
technical parameter
Parameter description
Model 1SAJ520000R0101 UMC100-FBP. 0 A4
Rated voltage 24-240 V AC/DC
Current range 0.24 A to 63 A
Working temperature -25 ° C to+70 ° C
FieldBusPlug (FBP) communication interface
Supports protocols such as Modbus, Profibus, Profinet, DeviceNet, etc
Installation method: DIN rail installation
Up to 6 digital inputs and 3 digital outputs for input and output
Protection functions include overload protection, short circuit protection, ground fault protection, and locked rotor protection
Display mode: Status LED or external HMI display
Protection level IP20
2.產 品 展 示
