SCHNEIDER MX-XF/SHT-SHC 電壓線圈 PDF資料
1.產 品 資 料 介 紹：
中文資料：
施耐德 MX-XF/SHT-SHC 電壓線圈 是一種專為工業斷路器或開關設備設計的附件組件，通常用于遠程控制和斷路器的保護操作。以下是關于該電壓線圈的詳細信息：
主要功能
MX-XF (分勵脫扣線圈)：
- 用于遠程斷開斷路器。
- 接收到電壓信號時，觸發斷路器跳閘，切斷電源。
- 通常用于緊急停機或保護性脫扣。
SHT-SHC (欠壓脫扣線圈)：
- 用于監控電源電壓狀態。
- 如果電壓低于設定值（欠壓條件），自動觸發斷路器跳閘。
- 用于防止設備在不穩定的電壓條件下運行，確保安全。
技術參數
| 參數 | 詳細信息 |
|---|---|
| 額定電壓范圍 | AC 或 DC 電壓，通常為 24V、48V、110V、220V 等多種規格 |
| 動作時間 | 通常 ≤ 50 ms |
| 功耗 | 根據線圈型號和電壓不同，約 3-8 W |
| 安裝位置 | 安裝于斷路器內部或附件插槽 |
| 操作溫度范圍 | -25°C 至 +70°C |
| 兼容設備 | Schneider 電氣斷路器（如 NSX 系列、Masterpact 等） |
| 耐久性 | 機械和電氣壽命均較高，適應頻繁操作需求 |
| 控制信號 | 標準電壓信號輸入 |
英文資料：
Schneider MX-XF/SHT-SHC voltage coil is an accessory component designed specifically for industrial circuit breakers or switchgear, typically used for remote control and circuit breaker protection operations. The following is detailed information about the voltage coil:
major function
MX-XF (shunt trip coil):
Used for remote disconnection of circuit breakers.
When receiving a voltage signal, trigger the circuit breaker to trip and cut off the power supply.
Usually used for emergency shutdown or protective tripping.
SHT-SHC (undervoltage trip coil):
Used to monitor the voltage status of the power supply.
If the voltage is lower than the set value (under voltage condition), the circuit breaker will automatically trip.
Used to prevent equipment from operating under unstable voltage conditions and ensure safety.
technical parameter
Detailed parameter information
The rated voltage range is AC or DC voltage, usually in various specifications such as 24V, 48V, 110V, 220V, etc
Action time is usually ≤ 50 ms
The power consumption varies depending on the coil model and voltage, about 3-8 W
Installation position: Installed inside the circuit breaker or in the accessory slot
Operating temperature range -25 ° C to+70 ° C
Compatible with Schneider electrical circuit breakers (such as NSX series, Masterpact, etc.)
Durable mechanical and electrical lifespan are both high, suitable for frequent operation needs
Control signal standard voltage signal input
2.產 品 展 示
