GE 193X264ABG01信號隔離器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X264ABG01 信號隔離器板（Signal Isolator Board） 是 GE（General Electric）193X 系列控制系統中的一款關鍵輔助模塊，主要用于實現控制系統中不同電氣回路之間的信號隔離、轉換與保護。這種模塊在大型工業自動化、發電機組、直流調速系統等應用場景中非常重要，特別適用于避免地電位差和干擾信號對控制邏輯的影響。
一、產品概述：
產品型號：193X264ABG01
類型：信號隔離器板（Signal Isolator）
系列歸屬：GE 193X 控制平臺
主要功能：電氣隔離、信號轉換、系統保護
二、核心功能：
電氣隔離
將控制電路與功率電路之間進行隔離，防止高壓或尖峰干擾傳入控制系統，保護內部精密元件。信號調理
對模擬輸入信號（如 4–20mA 或 0–10V）進行轉換或匹配，使其適應下游控制器或驅動模塊的輸入要求。抗干擾能力強
尤其適用于工業環境中 EMI（電磁干擾）嚴重的場合，具備良好的共模抑制比。信號放大與緩沖
具備一定的放大和緩沖功能，提升信號傳輸距離和穩定性。系統保護作用
一旦檢測到異常電壓或接地回路電流，可自動切斷信號路徑或發出報警。
三、典型應用領域：
| 行業 | 應用示例 |
|---|---|
| 發電與能源 | 汽輪機控制、發電機勵磁反饋隔離 |
| 鋼鐵冶金 | 電機速度、電流反饋信號隔離處理 |
| 化工自動化 | 工藝變量（如溫度、壓力）信號轉換與隔離 |
| 水泥與造紙 | 多系統協同控制信號調理 |
| 鐵路系統 | 軌道供電與信號控制隔離防護 |
英文資料：
The GE 193X264ABG01 Signal Isolator Board is a key auxiliary module in the GE (General Electric) 193X series control system, mainly used to achieve signal isolation, conversion, and protection between different electrical circuits in the control system. This module is very important in large-scale industrial automation, generator sets, DC speed control systems, and other application scenarios, especially suitable for avoiding the influence of ground potential difference and interference signals on control logic.
1、 Product Overview:
Product model: 193X264ABG01
Type: Signal Isolator Board
Series affiliation: GE 193X Control Platform
Main functions: electrical isolation, signal conversion, system protection
2、 Core functions:
Electrical isolation
Isolate the control circuit from the power circuit to prevent high voltage or spike interference from entering the control system and protect internal precision components.
signal-conditioning
Convert or match analog input signals (such as 4-20mA or 0-10V) to meet the input requirements of downstream controllers or drive modules.
Strong anti-interference ability
Especially suitable for industrial environments with severe EMI (electromagnetic interference), it has a good common mode rejection ratio.
Signal amplification and buffering
It has certain amplification and buffering functions to improve signal transmission distance and stability.
System protection function
Once abnormal voltage or grounding circuit current is detected, the signal path can be automatically cut off or an alarm can be issued.
3、 Typical application areas:
Industry application examples
Isolation of power generation and energy turbine control, generator excitation feedback
Isolation processing of speed and current feedback signals for steel metallurgy motors
Chemical automation process variables (such as temperature, pressure) signal conversion and isolation
Multi system collaborative control signal conditioning for cement and papermaking
Railway system track power supply and signal control isolation protection
