GE 193X532ACG01現場控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X532ACG01 現場控制板簡介
GE 193X532ACG01 是通用電氣（General Electric）公司生產的 193X 系列工業控制板之一，廣泛應用于早期的 GE 驅動控制系統中。它是一塊插拔式現場控制板，常見于各種重工業環境中的直流電機或交流電機控制系統中，用于信號處理和邏輯控制。
技術規格與功能
控制類型：模擬與數字信號混合控制
安裝方式：插卡式安裝，通過金手指連接到系統母板
電源要求：通常為 ±15V DC，需與系統電源匹配
信號輸入：電壓、電流、繼電器觸點信號等
信號輸出：控制驅動信號、模擬控制量、開關量輸出
組件特性：含多組可調電位器（用于增益、偏移調整）
電路結構：由分立元件、運算放大器、濾波器等構成
狀態指示：部分版本帶有 LED 狀態指示燈（用于調試或報警）
典型應用領域
GE Mark 系列驅動系統（如 Mark I、Mark II、Mark IV）
冶金、電解、電廠勵磁控制系統
工業直流/交流電機調速系統
老舊工業設備自動化改造與維修支持
使用注意事項
安裝前應確認系統是否斷電，避免插拔時引起電弧或短路。
安裝或維護過程中需采取防靜電措施，以防止元件損壞。
板卡參數必須與原設備系統匹配，包括電壓等級、接口定義和邏輯控制方式。
調試建議使用萬用表、示波器等儀表監測輸入輸出信號狀態。
長期運行建議每 6 至 12 個月進行維護檢查，重點關注接口接觸點、焊點和電解電容狀態。
英文資料：
Introduction to GE 193X532ACG01 Field Control Board
GE 193X532ACG01 is one of the 193X series industrial control boards produced by General Electric, widely used in early GE drive control systems. It is a plug-in field control board commonly used in DC or AC motor control systems in various heavy industrial environments for signal processing and logic control.
Technical specifications and functions
Control type: Mixed control of analog and digital signals
Installation method: Card insertion installation, connected to the system motherboard through a gold finger
Power requirements: typically ± 15V DC, to be matched with the system power supply
Signal input: voltage, current, relay contact signals, etc
Signal output: control drive signal, analog control quantity, switch quantity output
Component features: Contains multiple sets of adjustable potentiometers (for gain and offset adjustment)
Circuit structure: composed of discrete components, operational amplifiers, filters, etc
Status indicator: Some versions come with LED status indicator lights (for debugging or alarm purposes)
Typical application areas
GE Mark series drive systems (such as Mark I, Mark II, Mark IV)
Metallurgical, electrolytic, and power plant excitation control systems
Industrial DC/AC motor speed control system
Automation transformation and maintenance support for old industrial equipment
Precautions for use
Before installation, it should be confirmed whether the system is powered off to avoid arcing or short circuits caused by plugging and unplugging.
During installation or maintenance, anti-static measures should be taken to prevent component damage.
The parameters of the board must match the original equipment system, including voltage level, interface definition, and logic control mode.
Debugging suggestions include using multimeters, oscilloscopes, and other instruments to monitor the status of input and output signals.
It is recommended to conduct maintenance checks every 6 to 12 months for long-term operation, with a focus on interface contact points, solder joints, and electrolytic capacitor status.
