GE 193X543ADG02繼電器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X543ADG02 是通用電氣（General Electric）193X 系列中的一款多路繼電器輸出卡，主要應用于工業自動化系統、驅動控制系統中，用于完成電路切換、信號聯動、報警觸發、執行控制等任務。該模塊通過接收來自主控制單元的指令，驅動多個電磁繼電器，實現不同控制邏輯下的通斷動作。
該模塊廣泛用于 GE 的 DC/AC 驅動系統以及早期 Mark 系列控制系統，適合于工業設備啟停、故障保護、順序控制等場景。
技術參數與功能特點
產品型號：193X543ADG02
產品名稱：繼電器卡 / Relay Card
功能類型：電路開關控制、狀態切換、報警輸出等
通道數：一般包含 4~8 路獨立控制的繼電器（具體視實際版本而定）
觸點類型：常開（NO）/常閉（NC）干接點輸出
線圈驅動電壓：24V DC 或 ±15V DC（由系統供電）
觸點額定負載：約 1~2A @ 250V AC 或 30V DC（取決于繼電器規格）
響應時間：典型 10~20ms
控制方式：板載邏輯接口由主板控制，自動或程序觸發動作
接口形式：金手指連接器（用于插入 GE 控制框架背板）
板載保護電路：帶有續流二極管、防反接保護、電壓鉗位等電路
顯示功能：部分版本帶有 LED 指示燈，反映每路繼電器當前狀態
工作溫度范圍：-20°C ~ +70°C
尺寸：標準 193X 系列控制板尺寸，可熱插拔或模塊替換
功能應用
實現控制系統中的邏輯開關動作
控制電機啟停、風扇、泵或其他執行設備
系統報警聯動觸發（聲光報警器、斷電保護）
設備運行狀態切換（工作/待機/故障）
用于安全控制系統的隔離觸點輸出
英文資料：
GE 193X543ADG02 is a multi-channel relay output card in the General Electric 193X series, mainly used in industrial automation systems and drive control systems to complete tasks such as circuit switching, signal linkage, alarm triggering, and execution control. This module drives multiple electromagnetic relays by receiving instructions from the main control unit, achieving on-off actions under different control logics.
This module is widely used in GE's DC/AC drive systems and early Mark series control systems, suitable for industrial equipment start stop, fault protection, sequence control and other scenarios.
Technical parameters and functional characteristics
Product model: 193X543ADG02
Product Name: Relay Card
Function type: Circuit switch control, status switching, alarm output, etc
Number of channels: generally includes 4-8 independently controlled relays (depending on the actual version)
Contact type: normally open (NO)/normally closed (NC) dry contact output
Coil driving voltage: 24V DC or ± 15V DC (powered by the system)
Contact rated load: approximately 1~2A @ 250V AC or 30V DC (depending on relay specifications)
Response time: Typical 10-20ms
Control mode: The onboard logic interface is controlled by the motherboard and triggers actions automatically or through a program
Interface form: Gold finger connector (used for inserting into GE control frame backplane)
Onboard protection circuit: equipped with freewheeling diode, anti reverse protection, voltage clamp and other circuits
Display function: Some versions come with LED indicator lights that reflect the current status of each relay
Working temperature range: -20 ° C~+70 ° C
Size: Standard 193X series control board size, hot swappable or module replaceable
Functional application
Implement logical switch actions in the control system
Control the start stop of motors, fans, pumps, or other executing devices
System alarm linkage triggering (sound and light alarm, power-off protection)
Equipment operation status switching (working/standby/fault)
Isolation contact output for safety control systems
2.產 品 展 示
