GE 193X638AAC06電動電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X638AAC06 是通用電氣（General Electric）193X 系列中的一款重要控制模塊，常被稱作電動電路板（Motor Control Board）。該模塊專為 GE 工業控制系統中的驅動與調速應用設計，用于處理電機的啟動、運行、調速、停機及保護等功能。其適用于中大型工業設備中的 DC 或 AC 電機控制系統，廣泛部署在發電廠、冶金、石化等自動化場景中。
技術參數與功能特點
產品型號：193X638AAC06
產品名稱：電動電路板 / Motor Control Board
系列歸屬：GE 193X 模塊化控制系統
主要功能：
電機控制信號處理（啟停/加減速）
控制信號放大、隔離與驅動
電流/電壓反饋邏輯處理
啟動/停止邏輯判斷與控制
故障檢測（如過流、欠壓）邏輯保護
信號接口類型：TTL/CMOS邏輯、電壓/電流模擬信號
控制方式支持：閉環調速控制 / 開環邏輯控制
電源輸入：+5V、±15V DC（由系統供電）
板載元件：邏輯電路、驅動電路、比較器、繼電器、電容電阻組、接口接線排等
工作溫度范圍：-20°C ～ +70°C
安裝方式：插槽式，金手指接口，適配GE控制系統背板
外形尺寸：符合193X標準卡件規格，便于模塊化安裝與維護
指示功能：板載LED燈用于運行/故障狀態指示
功能作用
電動機邏輯控制：管理電機的啟動、運行、停止流程，并配合執行機構如接觸器/驅動器控制信號。
速度控制邏輯：根據反饋信號調節輸出，實現穩速運行或加/減速控制。
電氣信號處理：接收上位系統信號并進行變換、放大、驅動等操作。
系統聯動接口：與其他模塊（如統計板、過渡板、報警板等）聯動完成系統邏輯閉環。
故障檢測與反饋：可對電流、電壓、溫度等參數進行檢測并輸出故障報警信號。
英文資料：
GE 193X638AAC06 is an important control module in the General Electric 193X series, often referred to as the Motor Control Board. This module is designed specifically for drive and speed regulation applications in GE industrial control systems, used to handle functions such as motor start-up, operation, speed regulation, shutdown, and protection. It is suitable for DC or AC motor control systems in medium to large industrial equipment and widely deployed in automation scenarios such as power plants, metallurgy, and petrochemicals.
Technical parameters and functional characteristics
Product model: 193X638AAC06
Product Name: Electric Circuit Board/Motor Control Board
Series affiliation: GE 193X modular control system
Main functions:
Motor control signal processing (start stop/acceleration/deceleration)
Control signal amplification, isolation, and driving
Current/voltage feedback logic processing
Start/stop logic judgment and control
Fault detection (such as overcurrent and undervoltage) logic protection
Signal interface type: TTL/CMOS logic, voltage/current analog signal
Control mode support: closed-loop speed control/open-loop logic control
Power input:+ 5V, ± 15V DC (powered by the system)
Onboard components: logic circuit, driver circuit, comparator, relay, capacitor resistor group, interface wiring block, etc
Working temperature range:- 20°C ～ +70°C
Installation method: slot type, gold finger interface, compatible with GE control system backplane
Dimensions: Compliant with 193X standard card specifications, convenient for modular installation and maintenance
Indication function: Onboard LED lights are used for operation/fault status indication
function
Motor logic control: manages the starting, running, and stopping process of the motor, and cooperates with the executing mechanism such as contactors/drivers to control signals.
Speed control logic: Adjust the output based on feedback signals to achieve stable speed operation or acceleration/deceleration control.
Electrical signal processing: Receive signals from the upper system and perform operations such as transformation, amplification, and driving.
System linkage interface: It links with other modules (such as statistical board, transition board, alarm board, etc.) to complete the system logic loop.
Fault detection and feedback: It can detect parameters such as current, voltage, temperature, etc. and output fault alarm signals.
2.產 品 展 示
