GE 193X707AAG01電機現場控制卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X707AAG01 電機現場控制卡技術資料
產品型號：193X707AAG01
產品名稱：電機現場控制卡（Motor Field Control Card）
制造商：General Electric (GE)
系列：193X 系列工業控制板卡
功能分類：電機控制與現場調節模塊（Motor Control and Field Regulation）
應用領域：工業自動化、電機控制、過程控制系統等
一、產品功能
GE 193X707AAG01 電機現場控制卡主要用于電機驅動系統中，通過直接控制電機的現場運行情況，調節電機的轉速、功率輸出、啟停狀態等。該卡適用于需要實時控制電機或電動機的系統，可以提供高效的電機控制與調節功能，確保電機運行的穩定性與精度。
主要功能：
電機控制：實現電機的啟?？刂?、轉速調節和電流監測等功能，確保電機在負載變化時平穩運行。
現場調節：通過與電機的現場控制接口直接連接，實時調整電機的運行參數。
負載監測：監控電機的負載狀態，包括電流、電壓、溫度等，并根據需求調整控制策略。
過載保護：在電機過載或異常狀態時，自動停機或報警，防止設備損壞。
調速功能：支持電機轉速的精確調節，適應不同工作狀態和負載要求。
二、主要技術參數
| 參數項 | 說明描述 |
|---|---|
| 控制方式 | 模擬信號調節（如電流、電壓）、數字信號輸入控制（如開關量輸入） |
| 電機類型 | 適用于交流電機、直流電機、同步電機等多種電機類型 |
| 輸入信號類型 | 控制信號（開關量信號、模擬電壓信號等） |
| 輸出信號類型 | 電機控制信號，如調節電壓、電流或頻率信號 |
| 電源需求 | ±15V DC 或 24V DC（根據實際系統電源要求） |
| 負載電流監測 | 支持電流傳感器輸入，監測電機工作狀態及負載情況 |
| 環境溫度范圍 | -40°C 到 +85°C，適用于工業環境 |
| 卡片尺寸 | 標準 GE 插卡式模塊尺寸，符合 193X 系列格式 |
| 安裝方式 | 插卡式，適配 GE 193X 系列控制機架 |
| 通訊協議 | 支持 Modbus、Profibus 或其他工業協議 |
| 工作頻率范圍 | 支持寬頻帶輸入，適應多種工業控制需求 |
英文資料：
Technical Data of GE 193X707AAG01 Motor Field Control Card
Product model: 193X707AAG01
Product Name: Motor Field Control Card
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Function classification: Motor Control and Field Regulation module
Application areas: Industrial automation, motor control, process control systems, etc
1、 Product Features
The GE 193X707AAG01 motor field control card is mainly used in motor drive systems to directly control the on-site operation of the motor, adjust the motor's speed, power output, start stop status, etc. This card is suitable for systems that require real-time control of motors or electric motors, and can provide efficient motor control and regulation functions to ensure the stability and accuracy of motor operation.
Main functions:
Motor control: Implement functions such as start stop control, speed regulation, and current monitoring of the motor to ensure smooth operation during load changes.
On site adjustment: By directly connecting with the on-site control interface of the motor, the operating parameters of the motor can be adjusted in real time.
Load monitoring: Monitor the load status of the motor, including current, voltage, temperature, etc., and adjust the control strategy according to demand.
Overload protection: When the motor is overloaded or in an abnormal state, it automatically stops or alarms to prevent equipment damage.
Speed regulation function: supports precise adjustment of motor speed to adapt to different working conditions and load requirements.
2、 Main technical parameters
Parameter item description
Control methods include analog signal regulation (such as current and voltage) and digital signal input control (such as switch input)
Motor types are suitable for various types of motors such as AC motors, DC motors, synchronous motors, etc
Input signal type control signal (switch signal, analog voltage signal, etc.)
Output signal type motor control signal, such as regulating voltage, current or frequency signal
Power requirement ± 15V DC or 24V DC (depending on actual system power requirements)
Load current monitoring supports current sensor input to monitor motor operating status and load conditions
Environmental temperature range -40 ° C to+85 ° C, suitable for industrial environments
Card size standard GE plug-in card module size, in accordance with the 193X series format
Installation method: plug-in card, compatible with GE 193X series control rack
The communication protocol supports Modbus, Profibus, or other industrial protocols
The working frequency range supports wideband input and adapts to various industrial control requirements
2.產 品 展 示
