ABB GJR2390300R1010 81EA03B-E數碼輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB GJR2390300R1010，型號為 81EA03B-E，是一款數字輸出模塊，廣泛應用于A(yíng)BB Symphony Harmony系列控制系統中，用于將控制器的邏輯指令轉換成開關信號，控制現場設備如接觸器、電磁閥、指示燈等。
一、產品基本信息
產品編號：GJR2390300R1010
模塊型號：81EA03B-E
模塊類型：數字輸出模塊（Digital Output Module）
輸出通道數：通常為 16 或 32 路（視配置）
輸出類型：干接點或繼電器輸出，可驅動 24V DC 設備
電氣隔離：模塊輸出與內部邏輯電路之間具備光耦隔離
安裝方式：DIN 導軌或機架式安裝，適配 SC510 或 SC520 子模塊架
系統平臺：兼容 ABB Symphony Harmony 系統，使用 MasterBus 300 通訊
二、產品功能特點
實現 DCS 控制系統向現場設備發出數字開關指令
輸出穩定可靠，具有過流、過壓保護機制
每一路輸出狀態可實時監測
通道具有短路保護和模塊故障診斷能力
適用于高可靠性要求的連續過程工業
三、典型應用領域
發電廠與變電站自動化：控制斷路器、警示燈、接觸器等
石油化工行業：控制泵啟動、閥門啟閉、狀態指示
水處理系統：執行閥門、泵機控制命令
制造業自動控制系統：用于執行PLC或DCS發出的邏輯動作
冶金、礦山：控制重載開關、機械裝置驅動邏輯
英文資料：
ABB GJR2390300R1010， The model number is 81EA03B-E, which is a digital output module widely used in ABB Symphony Harmony series control systems. It is used to convert the logic instructions of the controller into switch signals and control field devices such as contactors, solenoid valves, indicator lights, etc.
1、 Basic Product Information
Product Code: GJR2390300R1010
Module model: 81EA03B-E
Module type: Digital Output Module
Number of output channels: usually 16 or 32 channels (depending on configuration)
Output type: dry contact or relay output, capable of driving 24V DC devices
Electrical isolation: there is optocoupler isolation between the module output and the internal logic circuit
Installation method: DIN rail or rack mounted, compatible with SC510 or SC520 submodule rack
System platform: compatible with ABB Symphony Harmony system, using MasterBus 300 communication
2、 Product functional features
Implement DCS control system to issue digital switch commands to on-site equipment
Stable and reliable output, with overcurrent and overvoltage protection mechanisms
Each output status can be monitored in real-time
The channel has short-circuit protection and module fault diagnosis capabilities
Suitable for continuous process industries with high reliability requirements
3、 Typical application areas
Automation of power plants and substations: controlling circuit breakers, warning lights, contactors, etc
Petrochemical industry: control pump start-up, valve opening and closing, status indication
Water treatment system: execute valve and pump control commands
Manufacturing automation control system: used to execute logical actions issued by PLC or DCS
Metallurgy and Mining: Control Heavy Duty Switches, Mechanical Device Drive Logic
