TRICONEX DI3301 數字輸入模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
型號：TRICONEX DI3301
類型：數字輸入模塊（Digital Input Module）
產品簡介
TRICONEX DI3301 是一款高可靠性的數字輸入模塊，設計用于 Triconex 三重冗余安全系統。它主要負責采集現場開關量信號，并提供三重化容錯架構下的安全數據采集功能，廣泛應用于對安全性要求極高的工業環境。
核心功能
接收來自現場設備的數字信號（如干觸點、限位開關、繼電器輸出等）
將信號輸入至 Tricon 控制器的冗余處理系統
提供信號濾波、隔離、防抖等功能，提高信號質量
支持與其他 I/O 模塊同步運行，實現安全控制邏輯
技術規格（典型參數，可能略有差異，具體以型號版本為準）
輸入通道數量：32 個獨立數字輸入通道
輸入電壓范圍：18–32 VDC（典型 24VDC）
輸入電流：每通道最大 6 mA
輸入類型：干接點或濕接點信號輸入
通道隔離：各輸入通道與系統總線隔離
冗余設計：每通道支持 TMR（三重冗余）輸入路徑
響應時間：≤ 5 ms（含濾波）
診斷功能：支持線路監測、斷線檢測、短路檢測等
工作溫度：-20°C ~ +60°C
存儲溫度：-40°C ~ +85°C
濕度范圍：5%–95% RH，無冷凝
英文資料：
Model: TRICONEX DI3301
Type: Digital Input Module
Product Introduction
Triconex DI3301 is a highly reliable digital input module designed for use in Triconex triple redundant safety systems. It is mainly responsible for collecting on-site switch signals and providing safety data acquisition function under a triple fault-tolerant architecture, widely used in industrial environments with extremely high safety requirements.
Core functions
Receive digital signals from on-site devices (such as dry contacts, limit switches, relay outputs, etc.)
Input the signal into the redundant processing system of the Tricon controller
Provide signal filtering, isolation, anti shake and other functions to improve signal quality
Support synchronous operation with other I/O modules to achieve safety control logic
Technical specifications (typical parameters, may vary slightly, please refer to the model version for details)
Number of input channels: 32 independent digital input channels
Input voltage range: 18-32 VDC (typical 24VDC)
Input current: Maximum 6 mA per channel
Input type: dry contact or wet contact signal input
Channel isolation: Each input channel is isolated from the system bus
Redundant design: Each channel supports TMR (Triple Redundancy) input path
Response time: ≤ 5 ms (including filtering)
Diagnostic function: supports line monitoring, disconnection detection, short circuit detection, etc
Working temperature: -20 ° C~+60 ° C
Storage temperature: -40 ° C~+85 ° C
Humidity range: 5% -95% RH, no condensation
2.產 品 展 示
