TRICONEX RO3451 控制器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
型號：TRICONEX RO3451
類型：數字輸出控制模塊（Relay Output Module）
產品概述
TRICONEX RO3451 是 Tricon 安全控制系統中的繼電器輸出模塊，用于將控制信號通過繼電器觸點形式傳遞至現場設備，適用于控制需要電氣隔離的負載設備，如接觸器、指示燈、警報器、繼電器等。
該模塊支持三重冗余配置，符合安全儀表系統（SIS）的高完整性要求，是 Tricon 系統中重要的安全輸出模塊之一。
模塊功能
提供 32 路獨立繼電器輸出通道
將數字控制信號轉換為繼電器觸點輸出
輸出信號具備電氣隔離，保護系統穩定運行
用于現場設備的控制與驅動
支持冗余架構同步工作，提升系統可用性
技術規格
輸出通道數量：32 點繼電器輸出
繼電器類型：Form A 單刀單擲（SPST-NO）干接點輸出
觸點額定容量：
最大電壓：30 VDC / 250 VAC
最大電流：2 A（阻性負載）
通道隔離：每個通道與系統電隔離
響應時間：約 10 毫秒以?xún)?/p>
輸出狀態顯示：前面板具備每通道 LED 狀態指示燈
模塊冗余：三通道獨立驅動、投票輸出機制，確保輸出可靠性
安裝結構：插拔式模塊，配合專用底座使用
熱插拔支持：模塊支持在線更換，無需系統下電
產品特點
三重冗余安全架構：每通道由三個獨立驅動器控制，滿足 SIL 3 要求
輸出保護：具備通道故障檢測、繼電器卡滯檢測功能
工業級設計：抗電磁干擾、高抗震性能、寬工作溫度范圍
維護便利：LED 狀態顯示與診斷信息便于快速定位故障
與系統兼容性強：可無縫集成至 Tricon 主控系統中
英文資料：
Model: TRICONEX RO3451
Type: Relay Output Module
product overview
TRICONEX RO3451 is a relay output module in the Tricon safety control system, used to transmit control signals to field devices through relay contacts. It is suitable for controlling load devices that require electrical isolation, such as contactors, indicator lights, alarms, relays, etc.
This module supports triple redundancy configuration and meets the high integrity requirements of Safety Instrumented Systems (SIS). It is one of the important safety output modules in the Tricon system.
Module functionality
Provide 32 independent relay output channels
Convert digital control signals into relay contact outputs
The output signal has electrical isolation to protect the stable operation of the system
Used for controlling and driving on-site equipment
Support redundant architecture synchronization work to improve system availability
technical specifications
Number of output channels: 32 relay outputs
Relay type: Form A Single pole Single throw (SPST-NO) dry contact output
Rated contact capacity:
Maximum voltage: 30 VDC/250 VAC
Maximum current: 2 A (resistive load)
Channel isolation: Each channel is electrically isolated from the system
Response time: within approximately 10 milliseconds
Output status display: The front panel has LED status indicators for each channel
Module redundancy: Three channel independent drive and voting output mechanism to ensure output reliability
Installation structure: Plug in module, used in conjunction with a dedicated base
Hot swappable support: Modules can be replaced online without the need for system power off
Product Features
Triple redundant safety architecture: Each channel is controlled by three independent drivers, meeting SIL 3 requirements
Output protection: equipped with channel fault detection and relay jamming detection functions
Industrial grade design: anti electromagnetic interference, high seismic performance, wide working temperature range
Easy maintenance: LED status display and diagnostic information facilitate quick fault location
Strong compatibility with the system: can be seamlessly integrated into the Tricon main control system
2.產 品 展 示
