WOODWARD 8200-1302
類型：伺服位置控制器（Servo Position Controller）
品牌：Woodward（伍德沃德，美國）
產品概述
WOODWARD 8200-1302 是一款高性能伺服位置控制器，專為工業發動機、燃氣輪機和蒸汽輪機等應用場合中的精確執行器控制而設計。其主要功能是根據輸入信號控制機械執行器的位置，實現閉環位置調節，廣泛用于能源、發電、石油天然氣等行業。
主要功能特點
高精度位置控制
實現對電動執行器或液壓執行器的精確調節（如閥門開度、進氣口等）。
多種輸入信號支持
可接受來自主控器或 PLC 的模擬控制信號（如 4–20 mA、0–5V、PWM 等）。
閉環控制算法
內置 PID 或自適應控制邏輯，自動調節響應時間與控制穩定性。
故障檢測功能
具備自診斷功能，檢測傳感器斷線、位置偏移、電壓異常等故障狀態。
兼容多種執行機構
支持多種 Woodward 電液、步進或伺服執行器，配置靈活。
典型技術參數
| 項目 | 參數說明 |
|---|---|
| 控制輸入 | 4–20 mA、0–5 V、PWM、CAN（部分版本） |
| 控制輸出 | 驅動信號輸出至伺服電機或執行機構 |
| 電源電壓 | 18–32 VDC，典型 24VDC |
| 工作溫度范圍 | -40°C 至 +85°C |
| 防護等級（面板） | 通常為 IP65（視安裝方式而定） |
| 通訊接口（部分型號） | CANopen、Modbus 或 Woodward 網絡(luò )協議 |
| 安裝方式 | 面板安裝或底板式固定安裝 |
英文資料：
WOODWARD 8200-1302
Type: Servo Position Controller
Brand: Woodward (Woodward, USA)
product overview
WOODWARD 8200-1302 is a high-performance servo position controller designed for precise actuator control in applications such as industrial engines, gas turbines, and steam turbines. Its main function is to control the position of mechanical actuators based on input signals, achieving closed-loop position adjustment, and widely used in industries such as energy, power generation, and oil and gas.
Main functional features
High precision position control
Realize precise adjustment of electric or hydraulic actuators (such as valve opening, air inlet, etc.).
Multiple input signal support
Can accept analog control signals from the main controller or PLC (such as 4-20 mA, 0-5V, PWM, etc.).
Closed loop control algorithm
Built in PID or adaptive control logic, automatically adjusting response time and control stability.
Fault detection function
Equipped with self diagnostic function, it can detect fault states such as sensor disconnection, position deviation, and abnormal voltage.
Compatible with multiple execution mechanisms
Supports multiple Woodward electro-hydraulic, stepper, or servo actuators with flexible configuration.
Typical technical parameters
Project parameter description
Control input 4-20 mA, 0-5 V, PWM, CAN (some versions)
Control the output of driving signals to servo motors or actuators
Power supply voltage 18-32 VDC, typical 24VDC
Working temperature range -40 ° C to+85 ° C
The protection level (panel) is usually IP65 (depending on the installation method)
Communication interface (some models) CANopen, Modbus or Woodward network protocol
Installation method: panel installation or bottom plate fixed installation
