MVME2100數據庫,MOTOROLA卡件
?事件計數-高達4GA的事件
?頻率測量-1.16 x 10-3 Hz至2.5 MHz
?周期/脈寬測量-400 ns至8.5899 x 106 s（32位浮點）點），400 ns到858 s（32位無符號整數）?方波/脈沖序列產生-0.0076 Hz至2.5 MHz?定時器/周期VMEbus斷續器-0.0076至1000 Hz?正交位置測量-正弦波/余弦高達1 MHz，32位計數器，極限/模檢查
?整數周期/脈沖寬度測量16位和32位，離散或不斷的低數據傳輸滯后
MVME2100數據庫?編程輸出-最多24個離散輸出?脈沖序列模式-具有可編程占空比的N個脈沖序列
?正交位置控制輸出-±1/4波控制分辨率；高達1.25 MHz步長和每個命令±32767步長
?整數QPM組捕獲-捕獲兩個整數QPM測量值同時
?事件觸發計時器延遲-生成高達131.1的VMEbus中斷事件邊緣輸入后的秒數；可再觸發
?24個控制/測量接口：24個時鐘、24個門、24個輸出?RS-422差分接口，支持單端TTL輸入
?選項允許配置4、8、16和24個接口?車載15 MHz 68HC000 CPU
?A32/A24/D32/D16/D8（EO）VME從接口，64 Kbyte VMEbus內存窗口
?數據交換接口：ANSI/IEEE標準754-1985，適用于32位浮點算術
?連續測量模式?VMEbus兼容ANSI/IEEE 1014-1987 IEC 821和297應用?旋轉軸儀器：角位置、速度、加速度?汽車行業測試：制動器、變速箱、轉速表?機器人技術?望遠鏡/天文臺?醫療/實驗室儀器?線性位置測量：距離、速度、加速度?電梯?橋式起重機?X-Y表格?機床
?自動存儲檢索? Event counting - up to 4 giga events
? Frequency measurement —1.16 x 10-3 Hz to 2.5 MHz
? Period/pulse-width measurement—400 ns to 8.5899 x 106 s (32-bit floating
point), 400 ns to 858 s (32-bit unsigned integer)
? Square wave/pulse train generation - 0.0076 Hz to 2.5 MHz
? Timer/periodic VMEbus interrupter - 0.0076 to 1,000 Hz
? Quadrature position measurement - sin/cos up to 1 MHz, 32-bit counters,
limit/modulo checking
? Integer period/pulse-width measurement 16- and 32-bit, discrete or
continuous; low data transport lags
? Programmed output - up to 24 discrete outputs
? Pulse sequence mode - train of N pulses with programmable duty cycle
? Quadrature position control outputs - ±1/4 wave control resolution; up to
1.25 MHz step rate and ±32767 steps per command
? Integer QPM group acquisition - captures two integer QPM measurements
simultaneously
? Event-triggered timer delay - generates VMEbus interrupt up to 131.1
seconds after event edge input; retriggerable
? 24 control/measurement interfaces: 24 clocks, 24 gates, 24 outputs
? RS-422 differential interface with support for single-ended TTL inputs
? Options allow configurations of 4, 8, 16, and 24 interfaces
? On-board 15 MHz 68HC000 CPU
? A32/A24/D32/D16/D8 (EO) VME slave interface, 64 Kbyte VMEbus
memory window
? Data exchange interface: ANSI/IEEE standard 754-1985 for 32-bit
floating-point arithmetic
? Continuous measurement modes
? VMEbus compatible ANSI/IEEE 1014-1987 IEC 821 and 297
APPLICATIONS
? Rotational shaft instrumentation: angular position, velocity, acceleration
? Automotive industry testing: brakes, transmissions, tachometer
? Robotics
? Telescope/observatory
? Medical/laboratory instruments
? Linear position measurement: distance, velocity, acceleration
? Elevators
? Overhead cranes
? X-Y tables
? Machine tools
? Automatic storage retrieval
