MVI56-PDPS通訊模塊,PROSOFT產品外觀
在整流過程中輸入的諧波和功率因數均可以控制。由于單元采用PWM整流，可以再生制動，四象限運行?？梢蕴峁╊~定容量80%的回饋能力，減速時可以將電機和負載的動能變成電能反饋回電網，無需制動電阻，就可以實現快速的減速和制動。MVe2變頻器輸入采用單相PWM整流、諧波極小，這樣使得輸入變壓器二次側繞組不需要移相，結構變得簡單；同時采用三電平IGBT串聯輸出，提高了單元耐壓等級、減少了單元數量使得輸入變壓器二次側繞組數量大大減少、工藝更簡單可靠。
MVI56-PDPS通訊模塊4）MVe2變頻單元的硬件構成
整流：IGBT、逆變：IGBT為三菱原裝產品，中間直流回路電容：可自愈式金屬薄膜電容，使用壽命長。
（5）變頻裝置保護配置：一次風機原10kV電源開關保護配置不變，作為旁路運行方式的保護。在變頻器上口開關柜配置CSC241C、保護裝置中設置第二套定值作為變頻方式運行的變壓器主保護。變頻裝置本體保護和電機的各種保護由變頻裝置自身保護功能實現。
2.6 緊急停機：變頻裝置自身帶有緊急停機按鈕。另外在電動機事故按鈕增加一對常開接點，接至變頻裝置用來在電動機故障時就地同時切除變頻裝置運行。
4 控制及邏輯說明
（1）變頻運行方式
正常運行期間兩臺一次風機變頻自動運行，動葉手動放置在60～80%開度，通過變頻器自動調節風機轉速，調整一次風壓；
（2）工頻運行方式
兩臺風機均工頻運行期間，保持原邏輯不變，通過調整風機動葉自動調節一次風壓；
（3）一臺變頻一臺工頻運行
1）變頻器投入自動調節一次風壓，工頻運行風機手動調節動葉開度，調整兩臺風機出力平衡；
2）工頻運行風機動葉投入自動調節一次風壓，變頻運行風機手動調節轉速，調整兩臺風機出力平衡；
