Sensor Signal Monitoring
The operation of the SIGNAL push-button allows the monitoring of the
selected channels sensor signal value. The displayed parameter is
dependent upon the type of sensor drive module fitted to the selected
channel card.
To enter the sensor signal monitoring operation, proceed as follows:
(1) Push and hold the required channel card RESET/SELECT pushbutton for approximately 1.5 seconds until the selected icon appears
on the channel display.
(2) Push the SIGNAL push-button and the selected
channel card display will indicate the sensor signal.
The displayed value will depend on the type of sensor
drive module fitted to the channel card as follows:
a. Catalytic Sensor Drive Module
The display will show the live bridge voltage
measured between 01 and 02 in mV. 02 is the
centre point of the second half of the Wheatstone
bridge which is on the channel card.
b. 4 - 20mA Sensor Drive Module
The display will show the live sensor loop current
in mA.
(3) Push the ( ) or ( ) push buttons or wait 30 seconds to exit the
SIGNAL mode.
4.7 View Clock/Calendar
The operation of the CLOCK push-button will cause the present time
and date to be displayed on a selected channel card.
Note: This operation requires a control card to be selected but the
operation has no effect on the selected control card, which is
used as a display device only.
To enter the clock/calendar operation, proceed as follows:
(1) Push and hold the required channel card RESET/SELECT pushbutton for approximately 1.5 seconds until the selected icon appears
on the channel display. Push the ALARMS push-button a second time and the selected
channel card display will indicate the A2 level alarm.
(4) Push the ALARMS push-button a third time and the selected
channel card display will indicate the A3 level alarm.
(5) Push the ALARMS push-button a fourth time and the selected
channel card display will indicate the STEL level alarm.
(6) Push the ALARMS push-button a fifth time and the selected channel
card display will indicate the LTEL level alarm.
(7) Further pushes of the ALARMS push-button will scroll through the
alarm level set points again. ie. A1, A2, A3, STEL and LTEL.
Note: Where an alarm function is disabled, the alarm threshold value
will be displayed as '- - - -' in the digital display.
(8) Push the ( ) or ( ) push-buttons or wait 30 seconds to exit the
ALARMS mode.
