PRODUCT SUPPORT
Product support can be obtained from a customer service center (i.e. Technical Support Group in North America or
a Technical Information Center (TIC) in Asia or Europe). Each region has a customer service center that provides
direct telephone support on technical issues related to the functionality, application, and integration of the product.
Regional contact information is provided below. Your regional Technical Support Group or TIC is the first place to
call when seeking product support information. When calling, it is helpful to have the following information ready:
? Product part number or model number and version
? If there is a problem with product operation:
- Whether or not the problem is intermittent
- The steps performed before the problem occurred
- Any status message, error messages, or LED indications displayed
- Installation environment EQUIPMENT DELIVERY AND HANDLING
1.4.1 Factory Shipment
Prior to shipment, a controller is fully tested and inspected to ensure proper operation. It is then packaged for
shipment. Most accessories are shipped separately.
1.4.2 Receipt of Shipment
Inspect each carton at the time of delivery for possible external damage. Any visible damage should be immediately
recorded on the carrier’s copy of the delivery slip.
Carefully unpack each carton and check the contents against the enclosed packing list. Inspect each item for any
hidden damage that may or may not have been accompanied by exterior carton damage.
If it is found that some items have been damaged or are missing, notify the Process Instrumentation Division of
Siemens Energy and Automation immediately and provide full details. In addition, damages must be reported to the
carrier with a request for their on-site inspection of the damaged item and its shipping carton.
1.4.3 Storage
If a controller is to be stored for a period prior to installation, review the environmental specifications in Section 14
Model Designation and Specifications.
As shipped, the MPU Controller board Real Time Clock Jumper (W7 or W8) is set to maximize battery life. If the
jumper has been set to enable Hot/Warm Start, or to confirm that the jumper is properly set, refer to Section 11
Maintenance and set the jumper for storage. Typical Shipment Contents
The items listed below are those typically included in a shipment and are subject to change.
1. Moore 353 Process Automation Controller, model number per order, qty. 1
2. Power Input and Range Resistor Kit, PN 16354-30, qty. 1
DESCRIPTION QUANTITY
Resistor, 250?, 0.1%, 3W, WW 3
Sleeving 3
Crimp-On Connector 6
Kit Installation Instruction 1
3. Mounting Clip Kit, no part number, qty. 1
Contents: 2 Mounting Clips and 2, 8-32 x 1 Screws (see the Parts List at back of this manual for part numbers)
4. I/O Expander Board Kits
PN16353-52 I/O Expander Board Kit - The I/O Expander Board is factory installed when a Moore 353 with
Expansion Board option 1 is ordered.
