SUB_ function blocks perform arithmetic subtraction on
the two input signals. Any unused input will be set to 0.0.
All inputs should have the same engineering units. If units
are not consistent, a SCL function block can be used or an
alternative is to use a MTH function block that has built-in
scaling functions. TAN__ function blocks, in firmware 1.30 and higher, accept a
radian input and output the tangent of that angle. TH_ function blocks can hold an initial value that will
transfer to the block output O1 on power up and it can be
used to track the TV input when input TC is high (1).
In 1.30 firmware or greater, the HOLD value can be
changed on line, using the pulser, when the TH_.O1 block
output is directly connected to X or Y inputs in an ODC
block. The range and resolution used by the pulser making
on line changes will be determined by the X Range or Y
Range inputsTOT_ function blocks accept a Boolean input and they
will retain a running total of the input transitions as the
block output as a real value for interconnection to other
blocks in the controller. The running total can be reset
when input R goes high (1). Input R is executed prior to
reading input S on each scan cycle.
Unconfigured inputs will be set to 0. When the
EDGETRIG parameter is set to 1, the total will
increment on each 0 to 1 transition on input S. When
the EDGETRIG parameter is set to 0, the total will
increment on each 1 to 0 transition.
The total will be retained during a WARM & HOT start
and will be initialized to 0.0 on a COLD start. TSW_ function blocks select one of two analog input
signals as the output signal. Input A becomes the output
when input SC is low (0) and input B will be the output
when input SC goes high (1).
Unconfigured inputs will default to SC=low(0), A=0.0,
B=100.0. XOR_ function blocks perform a logical exclusive OR
function on all three inputs. An unused input will cause the
block to function as a two input XOR. The XOR output
will be low (0) when all configured inputs are low (0) or
when all configured inputs are high (1). 4.0 FACTORY CONFIGURED OPTIONS
Factory Configured Options provide an easy way to configure a Model 352Plus, Model 353, or Model 354. In most
cases a Factory Configured Option (FCO) will provide a complete, functional loop controller, once the proper I/O
connections are made. Changes can be made to an FCO to meet individual requirements. The FCO listings on the
following pages document the parameters that are different than the default values listed in section 3.
