產品詳情介紹
A-B 81007-465-51-R電壓反饋模塊
輸出保護繼電器輸出可以通過以下方式進行外部保護，以防感應負載產生寄生蟲：-變阻器或RC模塊，交流-自由輪二極管，直流。外部熱熔斷器連接到輸出的公共電源，保護輸出連接的設備。1.4.7.4 CS 31總線的布線CS 31總線是RS 485串行接口，由屏蔽雙絞線組成。此總線是主從總線，僅接受單個主總線。使用AWG 24（0.22 mm 2）至AWG 18（0.18 mm 2）雙絞線。最大長度為500米。整個系統總線設置應使用相同的電纜類型。例如，在機柜電纜連接期間，應避免總線中斷，否則應將其連接到接線板的同一側。警告：不允許總線的STAR連接！中央和遠程裝置可連接在總線的任何點上：-總線1上的總線1-總線2上的總線2-端子排1的端子3上的屏蔽（最好是編織）和主級接地（電纜<1 m）?？偩€(xiàn)應以120? 連接至總線終端的1/4 W電阻。雙絞線應對稱
產品概述
Trusted?電源系統是一種高密度靈活電源，用于轉換110 Vac或240 Vac的主線電壓?？尚女a(chǎn)品的輸出為24 Vdc或28 Vdc可調現場電源。Trusted Power System由一個帶機械支撐的1U電源架組成，其中最多包含三個750 W電源組。電源組在使用一個或多個電源架的配置中共享負載。每個電源組都有一個單獨的電源連接，通過一個機械固定的IEC 60320型連接器。每個電源架可以從單個電源提供2250 W或1500 W的電源，并具有n+1冗余?？梢赃B接多個單元以滿足更多容量或冗余要求。電源組狀態的診斷信息通過連接到電源架后部的電源端口提供。該設備監測輸入和輸出條件，并使用繼電器觸點報告超出范圍的故障和超溫/風扇故障。電源端口還允許連接可選的機架式電源控制器，用于實時配置輸出電壓和電流，監控4個電源架中最多12個電源組。
特點：?冗余和N+1配置。?可熱更換電源組。?電流共享。?電流限制。?功率因數校正。?診斷觸點。?可配置輸出電壓。?每個電源組的輸入/輸出故障診斷。
Output protection
The relay outputs may be protected externally against parasites generated by an inductive load with: - a varistor or an RC module, in alternating current - a free-wheel diode, in direct current The presence of an external thermal fuse, connected to the common power supply of the outputs, protects to the output connected devices. 1.4.7.4 Cabling of the CS 31 bus The CS 31 bus is a RS 485 serial interface and consists of a shielded twisted pair. This bus is a master slave bus and only accepts a single master. Use a AWG 24 (0.22 mm 2 ) to AWG 18 (0.18 mm 2 ) twisted pair. The maximum length is 500 m. The same cable type should be used for the whole system bus setup. Bus interruptions should be avoided, during cabinet cable connections for instance, otherwise it should be cabled to the same side of the terminal block Warning: STAR connection of the bus is not permitted! The central and remote units may be connected at any point of the bus: - bus 1 on bus 1 - bus 2 on bus 2 - shielding (preferably braided) on terminal 3 of terminal block 1 and earth connected at the master level (cable < 1 m) The bus should be terminated with a 120 ? 1/4 W resistance connected to the bus extremities. The twisted pair should be symmetrical
Product Overview
The Trusted? Power System is a high density flexible power supply designed to convert main line voltages of either 110 Vac or 240 Vac. Outputs are either 24 Vdc for Trusted product or 28 Vdc adjustable field power. The Trusted Power System consists of a 1U Power Shelf with mechanical support, containing up to three 750 W Power Packs. The Power Packs load share in configurations using one or more Power Shelves. Each Power Pack has an individual supply connection via a mechanically retained IEC 60320 type connector. Each Power Shelf can supply 2250 W of power or 1500 W with n+1 redundancy from a single source. Multiple units can be connected for further capacity or redundancy requirements. Diagnostic information of Power Pack status is provided via the Power Port, which connects to the rear of the Power Shelf. This device monitors input and output conditions and reports out of range faults and over-temperature/fan failure using relay contacts. The Power Port also allows connection of the optional rack mounted Power Controller for live configuration, of output voltage and current, monitoring up to 12 Power Packs in 4 Power Shelves.
Features: ? Redundant and N+1 configurations. ? Hot replaceable Power Packs. ? Current sharing. ? Current limiting. ? Power factor correction. ? Diagnostic contacts. ? Configurable output voltage. ? Input/output fail diagnostics per power pack.
