HIMA F8652X安全控制系統
PQM出廠時將設定點編程為默認值。這些值顯示在所有設定點消息圖示中。許多出廠默認值可以保持不變。但是,至少必須輸入第21頁第4.3.1節:電流/電壓配置中陰影部分所示的設定值,系統才能正常工作。為了防止安裝未輸入設定值的PQM,PQM將報警并鎖定,直到輸入這些設定值。在PQM用這些臨界設定點編程之前,出現“未存儲臨界設定點”報警信息。]]S1 PQM設置]]設置點]]S2系統設置]]設置值]]S3輸出繼電器]]設置點]]S4警報/控制]]設置點[]S5測試]首選項]]設置點訪問]]COM 1 RS485]串行端口]COM 2 RS485]串口]前面板RS232]串行端口]DNP 3.0]配置
The PQM leaves the factory with setpoints programmed to default values. These values are shown in all the setpoint message illustrations. Many of these factory default values can be left unchanged. At a minimum however, setpoints that are shown shaded in Section 4.3.1: Current/Voltage Configuration on page –21 must be entered for the system to function correctly. In order to safeguard against the installation of a PQM whose setpoints have not been entered, the PQM will alarm and lock out until the values have been entered for these setpoints. The CRITICAL SETPOINTS NOT STORED alarm message is present until the PQM is programmed with these critical setpoints.]] S1 PQM SETUP ]] SETPOINTS ]] S2 SYSTEM SETUP ]] SETPOINTS ]] S3 OUTPUT RELAYS ]] SETPOINTS ]] S4 ALARMS/CONTROL ]] SETPOINTS ]] S5 TESTING ] PREFERENCES ] ] SETPOINT ACCESS ] ] COM 1 RS485 ] SERIAL PORT ] COM 2 RS485 ] SERIAL PORT ] FRONT PANEL RS232 ] SERIAL PORT ] DNP 3.0 ] CONFIGURATION
