KOLLMORGEN CE10560伺服驅動器電機
產品詳情資料：
KOLLMORGEN CE10560伺服驅動器電機I/O LINK主系統配置示例上圖顯示了一個簡單的I/O LINK系統：一個用作主系統的Series 90-30 PLC、一個Series 90-30手持式編程器、一個I/O LINK和一個從系統。在圖中，從屬設備是Power Mate CNC。其他可用作從設備的設備包括Series 90-70 PLC、KOLLMORGEN CE10560、Fanuc Series 0 CNC、Fanuc連接單元和Fanuc操作員面板。該模塊可使用Series 90-30手持式編程器（HHP）或組態軟件進行組態。任何數量的I/O LINK主模塊均可安裝在Series 90-30 PLC中。當同一PLC中有多個I/O LINK主模塊時，它們必須位于單獨的I/O LINK上。I/O LINK主模塊可以安裝在任何基板的任何I/O插槽中?？砂惭b在CPU基板上的I/O LINK主模塊的最大數量為六個，重新啟動按鈕如果發生故障，LINK Restart按鈕提供了一種方便的重新啟動方式。按下重啟按鈕可重啟LINK的操作。串行端口模塊的前端有一個20針本田型連接器，用于連接到I/O鏈路上的第一個從設備。信號電平與RS422/485兼容。KOLLMORGEN CE10560
Example of I/O LINK Master System Configuration The illustration above shows a simple I/O LINK system: a Series 90-30 PLC used as a master, a Series 90-30 Hand-held Programmer, an I/O LINK, and one slave. In the illustration, the slave is a Power Mate CNC. Other devices that can be used as slaves include the Series 90-70 PLC, the Series 90-30 PLC,KOLLMORGEN CE10560 the Fanuc Series 0 CNC, Fanuc Connection Units, and Fanuc Operator Panels. The module can be configured using a Series 90-30 Hand-held Programmer (HHP) or the configuration software.Any number of I/O LINK Master Modules can be installed in a Series 90-30 PLC. When there are multiple I/O LINK Master Modules in the same PLC, they must be on separate I/O LINKs. An I/O LINK Master Module can be installed in any I/O slot in any baseplate. KOLLMORGEN CE10560The maximum number of I/O LINK Master Modules that can be installed in the CPU baseplate is six,Restart Pushbutton The LINK RESTART pushbutton provides a convenient means of restart if a failure occurs. Pushing the Restart pushbutton restarts the operation of the LINK. Serial Port The front of the module has one 20-pin, Honda-type connector, used for connection to the first slave on the I/O LINK. Signal levels are RS422/485 compatible.KOLLMORGEN CE10560
品牌：KOLLMORGEN
型號：KOLLMORGEN CE10560
產品說明：伺服驅動器電機
特點：模塊/卡件，控制器，觸摸屏，伺服驅動器
優勢：供應進口原裝正品，專業停產配件。
