NI PXIe-2569多路復用繼電器模塊
1.產 品 資 料 介 紹：
中文資料：
NI PXIe-2569是一種多路復用（MUX）和繼電器切換模塊，是National Instruments（NI）的PXI Express（PXIe）系列產品之一。以下是有關其配置、功能和應用領域的說明：
配置說明：
- NI PXIe-2569是一種3插槽（3-slot）模塊，安裝在PXIe底座中使用。
- 它具有64個獨立的單極（single-pole）和單刀（single-throw）繼電器通道，分成8個組。每個組有8個通道，可以獨立地打開或關閉。
- 模塊采用了絲杠連接器（screw-terminal）連接器，可以方便地連接和斷開測試電路。
功能和作用：
- NI PXIe-2569的主要功能是在測試和測量應用中提供信號路由和切換的能力。它可以通過繼電器將測試信號路由到所需的位置，實現測試點的切換和配置。
- 該模塊支持高達300 V的電壓和1 A的電流，可以適應不同類型的測量和測試需求。
- 它還具有低電流漏失和高絕緣性能，以確保精確的信號傳遞和最小的串擾。
應用領域：
- 自動測試設備（ATE）：NI PXIe-2569可以在自動測試設備中用于信號路由和測試點切換，幫助測試工程師快速配置測試系統。
- 電子產品測試：在電子產品制造和測試過程中，該模塊可以用于信號切換、功能測試和電路連接的自動化。
- 通信和無線領域：PXIe-2569可用于通信設備測試、無線電頻率切換和天線選擇。
- 汽車電子：在汽車電子測試中，該模塊可以用于信號傳感器選擇、控制單元切換和電路連接。
總之，NI PXIe-2569是一款功能強大的多路復用和繼電器切換模塊，廣泛應用于測試和測量領域，特別是在自動測試設備、電子產品測試、通信和無線領域以及汽車電子中。
英文資料：
NI PXIe-2569 is a multiplexing (MUX) and relay switching module, and is one of the PXI Express (PXIE) series products of National Instruments (NI). The following is an explanation of its configuration, functions, and application areas:
Configuration instructions:
The NI PXIe-2569 is a 3-slot module that is installed and used in the PXIE base.
It has 64 independent single pole and single pole relay channels, divided into 8 groups. Each group has 8 channels that can be opened or closed independently.
The module adopts a screw terminal connector, which can easily connect and disconnect the test circuit.
Function and function:
The main function of NI PXIe-2569 is to provide signal routing and switching capabilities in testing and measurement applications. It can route test signals to the desired location through relays, achieving switching and configuration of test points.
This module supports a voltage of up to 300 V and a current of 1 A, and can adapt to different types of measurement and testing needs.
It also has low current leakage and high insulation performance to ensure accurate signal transmission and minimal crosstalk.
Application field:
Automatic Test Equipment (ATE): NI PXIe-2569 can be used in automatic test equipment for signal routing and test point switching, helping test engineers quickly configure test systems.
Electronic product testing: In the manufacturing and testing process of electronic products, this module can be used for signal switching, functional testing, and automation of circuit connections.
Communication and wireless fields: PXIe-2569 can be used for communication equipment testing, radio frequency switching, and antenna selection.
Automotive electronics: In automotive electronics testing, this module can be used for signal sensor selection, control unit switching, and circuit connection.
In summary, NI PXIe-2569 is a powerful multiplexing and relay switching module widely used in testing and measurement fields, especially in automatic testing equipment, electronic product testing, communication and wireless fields, and automotive electronics.
