Ethernet Interface Ports
The Ethernet Interface module has two auto-sensing 10Base T / 100Base TX RJ-45 shielded
twisted pair Ethernet ports for connection to either a 10BaseT or 100BaseTX IEEE 802.3
network. The port automatically senses the speed (10Mbps or 100Mbps), duplex mode (half
duplex or full duplex) and cable (straight-through or crossover) attached to it with no intervention
required.
Ethernet Media
The Ethernet Interface can operate directly on 10BaseT/100BaseTX media via its network ports.
10BaseT: 10BaseT uses a twisted pair cable of up to 100 meters in length between each node
and a switch, hub, or repeater. Typical switches, hubs, or repeaters support 6 to 12 nodes
connected in a star wiring topology.
100BaseTX: 100BaseTX uses a cable of up to 100 meters in length between each node and a
switch, hub, or repeater. The cable should be data grade Category 5 unshielded twisted pair
(UTP) or shielded twisted pair (STP) cable. Two pairs of wire are used, one for transmission,
and the other for collision detection and receive. Typical switches, hubs, or repeaters support 6
to 12 nodes connected in a star wiring topology.Station Manager
The built-in Station Manager function of the Ethernet Interface provides on-line supervisory
access to the Ethernet Interface, through the Station Manager port or over the Ethernet cable.
Station Manager services include:
? An interactive set of commands for interrogating and controlling the station.
? Unrestricted access to observe internal statistics, an exception log, and configuration
parameters. Firmware Upgrades
The Ethernet Interface receives its firmware upgrades indirectly from the PLC CPU using the
WinLoader software utility. WInLoader is supplied with any updates to the Ethernet Interface
software.
Ethernet Global Data (EGD)
Each PACSystems CPU supports up to 255 simultaneous Ethernet Global Data (EGD)
exchanges. EGD exchanges are configured using the programmer and stored into the PLC.
Both Produced and Consumed exchanges can be configured. PACSystems Ethernet Interfaces
support both selective consumption of EGD exchanges and EGD exchange production and
consumption to the broadcast IP address of the local subnet.
