The SCON status bit is a reflection of the configuration of
header J3. When J3 pins 1 and 2 are connected, enabling the
MVME147 to act as the VMEbus system controller, then SCON
= 1. When J3 pins 1 and 2 are not connected, the MVME147 is
not the VMEbus system controller and SCON = 0.
Bit 1 This bit allows the software to initiate a global reset sequence.
Setting the SRESET bit activates the SYSRESET* signal on the
VMEbus which in turn resets the MVME147. This bit clears
automatically after the reset is complete. This bit is cleared by
any reset.
Bit 2 Setting BRDFAIL to 1 causes the VMEchip to attempt to activate
the SYSFAIL* signal on the VMEbus. The GCSR bit Inhibit
SYSFAIL (ISF), in global register 1, enables the MVME147 to
cause SYSFAIL* to be activated as a result of the state of
BRDFAIL. In addition, when the bit is set, the FAIL LED is lit. (A
watchdog time-out from the PCC also lights the FAIL LED.)
This bit is set by any reset.
Bit 3 The ROBIN bit configures the VMEbus arbitration mode.
ROBIN = 1 forces the round-robin mode. ROBIN = 0 forces the
priority mode. Both modes can be used by the MVME147. This
bit is cleared by SYSRESET. These bits are set to 1, 1 by any reset.
Note that writes to REQLEV1,0 do not change the actual
requester level until the MVME147 goes through the action of
having VMEbus mastership and releasing it. This means that
there are times when the value written into REQLEV1,0 do not
match the current requester level (the request level is lagging).
During such times, reads to REQLEV1,0 reflect the actual
requester level, not the value written into REQLEV1,0.
Bit 3 Setting this bit to 1 prevents the requester from releasing the
VMEbus. However, unlike the DWB control bit, setting the
RNEVER bit does not cause the requester to request the
VMEbus. Clearing the RNEVER bit allows the requester to
relinquish the VMEbus in accordance with the other control bits
of the requester configuration register. This bit is cleared by any
reset.
