using the address contained in the data address register. Data
transfers continue until the byte count register reaches 0.
At this point, the DMAC sets the done bit and enters the idle state
unless more table walking is indicated by the link bit in the byte
count register.
Table Walk State
The table address and table function code registers point to the
DMAC table. Table 5-1 is an example. The table has two entries for
each data block: the data address and the byte count.
When the DMAC table walks, it copies the first longword from the
table into the table address register, and the second longword from
the table into the byte count register. It then goes to the data transfer
state. If the table walk caused the link bit to be set, the DMAC table
walks again after the data transfer state has ended.
Note The DMAC table must always be placed within 32-bit
memory. The PCC terminates if 8-bit or 16-bit memory
is encountered during a table walk.SCSI Data Bus Converter
The WD33C93 connects to a separate 8-bit data bus on the PCC and
not to the local MC68030 bus. This allows the PCC to collect one
longword of data by transferring one byte at a time from the
WD33C93 without using the processor bus. When a longword is
ready, the chip requests the local bus and transfers it. This scheme
lightens the load on the MC68030 local bus.
SCSI Chip Interface
The PCC provides the interface for MC68030 accesses of the
WD33C93. It uses the nonmultiplexed mode which requires that
the software use the WD33C93 pointer registers to access its
internal registers. The WD33C93 registers are accessible indirectly
through the address register at $FFFE4000.
Programmable Tick Timers
The PCC features two 16-bit programmable tick timers. A timer
generates a periodic interrupt to the MC68030 at the programmed
rate. The period is 6.25 μs to 0.4 seconds in 6.25 μs increments. The
timer may also be disabled. The timer interrupt level is
programmable and it provides a status/ID vector when its
interrupt is acknowledged.
