SCSI Interface
The MVME162 supports mass storage subsystems through the industrystandard SCSI bus. These subsystems may include hard and floppy disk
drives, streaming tape drives, and other mass storage devices. The SCSI
interface is implemented using the NCR 53C710 SCSI I/O controller.
Support functions for the NCR 53C710 are provided by the MCchip. Refer to
the NCR 53C710 user’s guide and to the MVME162 Embedded Controller
Programmer’s Reference Guide for detailed programming information. Refer to
the MVME712-12, MVME712-13, MVME712A, MVME712AM, and
MVME712B Transition Modules and LCP2 Adapter Board User’s Manual or to the
MVME712M Transition Module and P2 Adapter Board User’s Manual for the pin
assignments of the transition module SCSI connectors.
SCSI Termination
The individual configuring the system must ensure that the SCSI bus is
properly terminated at both ends.
The MVME162 provides sockets for SCSI bus terminators on the P2 adapter
board or the LCP2 adapter board. If the SCSI bus ends at the adapter board,
then termination resistors must be installed on the adapter board. +5V power
to the SCSI bus TERMPWR signal and termination resistors is provided
through a fuse located on the adapter board.
Local Resources
The MVME162 includes many resources for the local processor. These include
tick timers, software programmable hardware interrupts, watchdog timer,
and local bus timeout.Programmable Tick Timers
Four 32-bit programmable tick timers with 1 μs resolution are provided in the
MCchip and two 32-bit programmable tick timers are provided in the optional
VMEchip2. The tick timers can be programmed to generate periodic
interrupts to the processor. Refer to the MCchip and VMEchip2 descriptions
in the MVME162 Embedded Controller Programmer’s Reference Guide for detailed
programming information.
Watchdog Timer
A watchdog timer is provided in both the MCchip and the optional VMEchip2.
The timers operate independently but in parallel. When the watchdog timers
are enabled, they must be reset by software within the programmed time or
they will time out. The watchdog timers can be programmed to generate a
SYSRESET signal, local reset signal, or board fail signal if they time out. Refer
to the VMEchip2 and MCchip descriptions in the MVME162 Embedded
Controller Programmer’s Reference Guide for detailed programming information.
