The MVME172LX comes with 172Bug firmware installed. For the
firmware to operate properly with the board, you must follow the steps
below. Inserting or removing boards with power applied may damage
board components.
1. Turn all equipment power OFF. Refer to MVME172LX
Configuration on page 1-4 and configure jumpers on headers as
necessary for your particular application.
a. The jumper block for header J21 contains eight bits, which all
affect 172Bug operation. They are read as a register (at location
$FFF4202D) on the MC2chip ASIC. (The MVME172 VME
Embedded Controller Programmer’s Reference Guide contains
additional information on the MC2chip.)
The bit values are read as a 0 when the corresponding jumper is
installed, or as a 1 when the jumper is removed.
The default configuration for J21 on the MVME172LX has
seven jumpers installed (no jumper between pins 9-10).
The 172Bug firmware reserves/defines the four lower order bits
(GPI3 to GPI0). Table 2-2 describes the bit assignments on J21.
b. Configure header J1 by installing/removing a jumper between
pins 1 and 2. A jumper installed/removed enables/disables the
system controller function on the MVME172LX.
2. Refer to the setup procedure for your particular chassis or system for
details concerning the installation of the MVME172LX. 3. Connect the terminal that is to be used as the 172Bug system
console to the default debug EIA-232-D port at serial port 1 on the
front panel of the MVME172LX. Refer to Serial Connections in
Chapter 1 for other connection options. Set the terminal up as
follows:
– Eight bits per character
– One stop bit per character
– Parity disabled (no parity)
– Baud rate 9600 baud (default baud rate of MVME172LX ports
at powerup)
After power-up, you can reconfigure the baud rate of the debug port
by using the 172Bug Port Format (PF) command.
