Turn all equipment power OFF and disconnect the power
cable from the AC power source. 2. Remove chassis cover as instructed in the equipment user's
manual.
3. Remove the filler panel(s) from the appropriate card slot(s) at
the front and rear of the chassis (if the chassis has a rear card
cage). The MVME177 module requires power from both P1
and P2. It may be installed in any double-height unused card
slot, if it is not configured as system controller. If the
MVME177 is configured as system controller, it must be
installed in the leftmost card slot (slot 1) to correctly initiate
the bus-grant daisy-chain and to have proper operation of the
IACK-daisy-chain driver. Install the MVME177 in the front of
the chassis. You can install the MVME712x in the front or the
rear of the chassis. Other modules in the system may have to
be moved to allow space for the MVME712M which has a
double-wide front panel.
4. Carefully slide the MVME177 module into the card slot. Be
sure the module is seated properly into the P1 and P2
connectors on the backplane. Do not damage or bend
connector pins. Fasten the module in the chassis with screws provided, making good contact with the transverse mounting
rails to minimize RFI emissions.
5. Remove IACK and BG jumpers from the header on the
chassis backplane for the card slot in which the MVME177 is
installed.
6. Connect the P2 Adapter Board and specified cable(s) to the
MVME177 at P2 on the backplane at the MVME177 slot, to
mate with (optional) terminals or other peripherals at the
EIA-232-D serial ports, parallel port, SCSI ports, and LAN
Ethernet port. Refer to the manuals listed in Related
Documentation in Chapter 1 for information on installing the
P2 Adapter Board and the MVME712x transition module(s).
(Some connection diagrams are in the Single Board Computers
Programmer's Reference Guide). Some cable(s) are not provided
with the MVME712x module(s), and therefore are made or
provided by the user. (Motorola recommends using shielded
cables for all connections to peripherals to minimize
radiation). Connect the peripherals to the cable(s). Detailed
information on the EIA-232-D signals supported is found in
Appendix A.
7. Connect the terminal to be used as the 177Bug system console
to the default debug EIA-232-D port at serial port 1 on
backplane connector P2 through an MVME712x transition
module. Refer to the Single Board Computers Programmer's
Reference Guide for some possible connection diagrams. Set up
the terminal as follows:
? Eight bits per character
? One stop bit per character
? Parity disabled (no parity)
? Baud rate 9600 baud (default baud rate of MVME177
ports at power-up)
After power-up, the baud rate of the debug port can be
reconfigured by using the Port Format (PF) command of the
177Bug debugger.
