HONEYWELL SC-UCMX01 51307195-175 混合I/O模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
HONEYWELL SC-UCMX01 51307195-175 混合I/O模塊 是一款用于 Honeywell 控制系統中的模塊化硬件，主要用于工業自動化系統中進行數據采集、信號處理和控制。它是 Honeywell SC 系列控制系統的一部分，廣泛應用于過程控制、設備監控和自動化系統中。
SC-UCMX01 51307195-175 混合I/O模塊主要特點：
混合I/O功能：
- SC-UCMX01 模塊支持 混合輸入/輸出功能，可以同時處理 數字輸入（DI）、數字輸出（DO）、模擬輸入（AI） 和 模擬輸出（AO） 信號。這樣可以在一個模塊中集成多種不同的 I/O 功能，節省系統空間和接線復雜度。
- 支持高效的數據采集與控制，能夠與不同的傳感器、執行器和控制設備配合使用。
高精度模擬信號：
- 提供 高精度的模擬輸入和輸出，支持標準電壓、電流信號（如 4-20 mA、0-10 V 等）。這種精度對于精確控制過程和設備非常關鍵。
- 對于模擬輸出，能夠精確控制設備的輸出信號，如閥門控制、電機調速等。
數字輸入/輸出：
- 數字輸入用于采集開關量信號，常用于設備狀態監測（如開關量傳感器、按鈕等）。
- 數字輸出可用于控制設備（如繼電器、報警燈、電磁閥等），為執行器提供控制信號。
模塊化設計：
- 模塊化設計使得 SC-UCMX01 能夠靈活地與其他 Honeywell 系列模塊進行集成，方便擴展系統容量和功能。
- 支持 熱插拔，即在系統運行的情況下進行更換或添加模塊，減少停機時間。
遠程I/O支持：
- SC-UCMX01 兼容 Honeywell 的 遠程I/O架構，支持通過通信網絡(luò )連接到控制器，允許將 I/O 點分布在現場設備和控制系統之間，節省布線和提升系統可靠性。
通信接口：
- 通常與 Honeywell Experion PKS 和 TDC 3000 控制系統兼容，支持各種工業通信協議（如 Modbus RTU/TCP、HART、Profibus 等），可以與第三方設備進行無縫集成。
- 內置 診斷功能，可以監控和報告模塊的狀態，確保系統運行的穩定性。
可靠性和安全性：
- 該模塊符合工業標準，能夠在惡劣環境下運行，抗干擾能力強。
- 具備 冗余設計，提高系統的可用性和故障恢復能力，尤其適用于關鍵的過程控制應用。
環境適應性：
- 適應廣泛的工作溫度范圍，一般支持 -20°C 至 +60°C 的工作環境，能夠在溫差較大的工業現場工作。
- 具備抗震動、抗沖擊和抗電磁干擾的能力，適合惡劣工業環境。
技術規格：
| 參數 | 說明 |
|---|---|
| 模塊類型 | 混合I/O模塊 |
| 輸入信號類型 | 模擬輸入（4-20 mA、0-10 V）、數字輸入 |
| 輸出信號類型 | 模擬輸出（4-20 mA、0-10 V）、數字輸出 |
| 模擬輸入精度 | 12-bit 或 16-bit（具體視型號而定） |
| 數字輸入/輸出電壓范圍 | 24V DC，兼容多種輸入輸出配置 |
| 支持的通信協議 | Modbus RTU/TCP、HART、Profibus 等 |
| 工作溫度范圍 | -20°C 至 +60°C |
| 模塊尺寸 | 適配標準 DIN 尺寸，便于安裝和維護 |
| 電源要求 | 24V DC |
| 模塊安裝方式 | 支持DIN導軌安裝，便于現場部署 |
| 冗余支持 | 支持模塊冗余，提高系統可靠性 |
| 診斷與故障檢測功能 | 內置診斷系統，支持狀態監控與報警 |
英文資料：
HONEYWELL SC-UCMX01 51307195-175 hybrid I/O module is a modular hardware used in Honeywell control systems, mainly for data acquisition, signal processing, and control in industrial automation systems. It is part of the Honeywell SC series control system, widely used in process control, equipment monitoring, and automation systems.
SC-UCMX01 51307195-175 Hybrid I/O Module Main Features:
Mixed I/O function:
The SC-UCMX01 module supports mixed input/output functionality and can simultaneously process digital input (DI), digital output (DO), analog input (AI), and analog output (AO) signals. This can integrate multiple different I/O functions in one module, saving system space and wiring complexity.
Supports efficient data collection and control, and can be used in conjunction with different sensors, actuators, and control devices.
High precision analog signal:
Provide high-precision analog input and output, supporting standard voltage and current signals (such as 4-20 mA, 0-10 V, etc.). This precision is crucial for precise control of processes and equipment.
For analog output, it can accurately control the output signals of equipment, such as valve control, motor speed regulation, etc.
Digital input/output:
Digital input is used to collect switch signals and is commonly used for device status monitoring (such as switch sensors, buttons, etc.).
Digital output can be used to control devices such as relays, alarm lights, solenoid valves, etc., providing control signals for actuators.
Modular design:
The modular design allows SC-UCMX01 to be flexibly integrated with other Honeywell series modules, facilitating the expansion of system capacity and functionality.
Support hot swapping, which means replacing or adding modules while the system is running to reduce downtime.
Remote I/O support:
SC-UCMX01 is compatible with Honeywell's remote I/O architecture and supports connection to controllers through communication networks, allowing I/O points to be distributed between field devices and control systems, saving wiring and improving system reliability.
Communication interface:
It is usually compatible with Honeywell Expert PKS and TDC 3000 control systems, supports various industrial communication protocols (such as Modbus RTU/TCP, HART, Profibus, etc.), and can be seamlessly integrated with third-party devices.
Built in diagnostic function, which can monitor and report the status of modules to ensure the stability of system operation.
Reliability and safety:
This module complies with industrial standards, can operate in harsh environments, and has strong anti-interference capabilities.
Equipped with redundant design to improve system availability and fault recovery capabilities, especially suitable for critical process control applications.
Environmental adaptability:
Adapt to a wide range of working temperatures, generally supporting working environments from -20 ° C to+60 ° C, and able to work in industrial sites with large temperature differences.
Capable of resisting vibration, impact, and electromagnetic interference, suitable for harsh industrial environments.
Technical specifications:
Parameter Description
Module type mixed I/O module
Input signal type: Analog input (4-20 mA, 0-10 V), digital input
Output signal type: Analog output (4-20 mA, 0-10 V), digital output
Analog input accuracy of 12 bit or 16 bit (depending on the model)
Digital input/output voltage range 24V DC, compatible with multiple input/output configurations
Supported communication protocols include Modbus RTU/TCP, HART, Profibus, etc
Working temperature range -20 ° C to+60 ° C
The module size is compatible with standard DIN dimensions, making it easy to install and maintain
Power requirement 24V DC
The module installation method supports DIN rail installation, making it easy to deploy on site
Redundancy support supports module redundancy to improve system reliability
The diagnosis and fault detection function is equipped with a built-in diagnostic system, which supports status monitoring and alarm
