A-B 1734-ACNR 網絡(luò )適配器器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Allen-Bradley 1734-ACNR 網絡(luò )適配器 是專為 ControlNet 網絡(luò ) 設計的設備，它可以將 POINT I/O 模塊 連接到 ControlNet 網絡(luò )中，支持分布式 I/O 系統。
主要特點：
- 高速數據傳輸：適配器支持高速的實時數據交換，確保設備與控制系統之間的快速通訊。
- 冗余功能：它支持 網絡(luò )冗余 和 控制器冗余，提供更高的系統可靠性和容錯能力。
- 抗干擾能力：在工業環境中，適配器具備較強的抗電磁干擾（EMI）能力，保證穩定運行。
- 網絡(luò )供電：適配器能夠通過網絡(luò )獲得供電，簡化了布線和安裝工作。
技術規格：
- 電源要求：輸入電壓為 24V DC，支持寬電壓范圍 10–28.8V DC。
- 功耗：功耗為 8W，最大功率損耗為 2.8W。
- POINTBus 電流：提供最大 1000 mA 的 5V 電流，支持多個 I/O 模塊。
- 模塊容量：最多支持連接 63 個 I/O 模塊。
應用領域：
- 工業自動化：用于將 POINT I/O 模塊集成到 ControlNet 網絡(luò )中，幫助實現靈活的自動化控制。
- 過程控制：在需要高速和可靠數據傳輸的過程控制系統中應用。
- 制造業：用于實時數據采集與控制，連接各類現場設備。
安裝與兼容性：
- 安裝方式：可以方便地通過 DIN 導軌進行安裝，符合工業標準。
- 兼容性：與 Allen-Bradley 的 POINT I/O 模塊和 ControlNet 網絡(luò )完美兼容。
Allen-Bradley 1734-ACNR 網絡(luò )適配器，憑借其冗余設計、高速數據傳輸和強抗干擾能力，是在要求高可靠性和穩定性的工業自動化環境中理想的網絡(luò )連接方案。
英文資料：
The Allen Bradley 1734-ACNR network adapter is a device designed specifically for ControlNet networks, which can connect POINT I/O modules to the network and support distributed I/O systems.
Main features:
High speed data transmission: The adapter supports high-speed real-time data exchange, ensuring fast communication between the device and the control system.
Redundancy function: It supports network redundancy and controller redundancy, providing higher system reliability and fault tolerance.
Anti interference capability: In industrial environments, adapters have strong anti electromagnetic interference (EMI) capabilities to ensure stable operation.
Network power supply: The adapter can obtain power through the network, simplifying wiring and installation work.
Technical specifications:
Power requirements: Input voltage is 24V DC, supporting a wide voltage range of 10-28.8V DC.
Power consumption: The power consumption is 8W, and the maximum power loss is 2.8W.
POINT Bus current: Provides a maximum of 1000 mA of 5V current and supports multiple I/O modules.
Module capacity: Supports up to 63 I/O modules for connection.
Application areas:
Industrial automation: used to integrate POINT I/O modules into the ControlNet network, helping to achieve flexible automation control.
Process control: applied in process control systems that require high-speed and reliable data transmission.
Manufacturing industry: used for real-time data collection and control, connecting various on-site devices.
Installation and compatibility:
Installation method: It can be easily installed through DIN rails, in compliance with industry standards.
Compatibility: Perfectly compatible with Allen Bradley's POINT I/O module and ControlNet network.
The Allen Bradley 1734-ACNR network adapter, with its redundant design, high-speed data transmission, and strong anti-interference capability, is an ideal network connection solution in industrial automation environments that require high reliability and stability.
2.產 品 展 示
