NI CRI0-9073 控制器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
NI CRIO-9073 控制器模塊 是 National Instruments (NI) 提供的一款基于 CompactRIO (cRIO) 系統的控制器，廣泛應用于嵌入式控制和自動化任務。它結合了高性能的處理能力和靈活的 I/O 配置，適用于各種工業應用。
主要特點：
- 高性能處理器：配備 Intel Atom 處理器，提供強大的計算能力，適應復雜的控制和數據處理需求。
- 模塊化設計：通過插入不同的 I/O 模塊，用戶可以根據需要定制系統的輸入輸出配置，支持模擬、數字、計數、熱電偶等多種信號。
- 實時操作系統：運行 NI Linux Real-Time 操作系統，確保高可靠性和實時性，適合工業控制和數據采集任務。
- 集成網絡(luò )功能：支持多種工業通信協議，如 Ethernet、Modbus TCP 等，能夠輕松集成到現有的控制系統中。
- 便于開發和部署：提供 LabVIEW 開發環境，使得系統開發、測試和部署變得簡單快捷。
技術規格：
- 處理器：Intel Atom 處理器，提供高效的計算能力，滿足大部分工業控制需求。
- 操作系統：NI Linux Real-Time，專為實時控制任務設計，確保系統響應速度和穩定性。
- I/O 模塊支持：支持多種類型的 I/O 模塊（模擬、數字、溫度等），適應不同的應用需求。
- 網絡(luò )接口：具備 Ethernet 端口，支持工業網絡(luò )協議，可以連接到多個設備，進行數據通信。
- 存儲：內置閃存，用于存儲操作系統、應用程序和數據，支持 SD 卡擴展存儲。
- 電源要求：通常工作在 9-30 V DC 的電壓范圍內。
應用領域：
- 工業自動化：用于工業生產線的控制系統中，能夠實時采集和控制多種設備。
- 測試與測量：適用于嵌入式測試系統和實驗設備的監控和數據采集。
- 數據采集與監控：用于采集來自傳感器的數據，并進行實時處理、報警、數據記錄等操作。
- 機器人控制：可以作為機器人系統的核心控制單元，實現自主運動控制和傳感器數據處理。
- 過程控制：在化工、電力等過程控制行業中，確保生產過程的自動化和監控。
英文資料：
The NI CRIO-9073 controller module is a controller provided by National Instruments (NI) based on the CompactRIO (cRIO) system, widely used in embedded control and automation tasks. It combines high-performance processing capabilities and flexible I/O configurations, making it suitable for various industrial applications.
Main features:
High performance processor: equipped with Intel Atom processor, providing powerful computing power to meet complex control and data processing requirements.
Modular design: By inserting different I/O modules, users can customize the input and output configuration of the system according to their needs, supporting various signals such as analog, digital, counting, thermocouple, etc.
Real time operating system: Run NI Linux Real Time operating system to ensure high reliability and real-time performance, suitable for industrial control and data acquisition tasks.
Integrated network functionality: Supports multiple industrial communication protocols such as Ethernet, Modbus TCP, etc., making it easy to integrate into existing control systems.
Easy to develop and deploy: Provides LabVIEW development environment, making system development, testing, and deployment simple and fast.
Technical specifications:
Processor: Intel Atom processor, providing efficient computing power to meet most industrial control needs.
Operating System: NI Linux Real-Time， Specially designed for real-time control tasks, ensuring system response speed and stability.
I/O module support: Supports multiple types of I/O modules (analog, digital, temperature, etc.) to meet different application requirements.
Network Interface: Equipped with Ethernet ports, supports industrial network protocols, and can connect to multiple devices for data communication.
Storage: Built in flash memory for storing operating systems, applications, and data, supporting SD card expansion storage.
Power Requirements: Typically operates within a voltage range of 9-30 V DC.
Application areas:
Industrial automation: used in control systems for industrial production lines, capable of real-time acquisition and control of various devices.
Testing and Measurement: Suitable for monitoring and data acquisition of embedded testing systems and experimental equipment.
Data collection and monitoring: used to collect data from sensors and perform real-time processing, alarm, data recording, and other operations.
Robot control: It can serve as the core control unit of robot systems, achieving autonomous motion control and sensor data processing.
Process control: Ensure the automation and monitoring of production processes in industries such as chemical and electrical control.
2.產 品 展 示
