Vibro-Meter 200-570-101-015 RLC16-V111印刷電路板PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
Vibro-Meter 200-570-101-015 RLC16-V111 是一款用于機器狀態監測和振動保護系統的 RLC16 系列印刷電路板（PCB）。它通常用于工業旋轉設備的振動測量、報警、保護系統中，屬于Vibro-Meter VM600系列或類似平臺中的功能模塊。
該板卡通過多個通道處理來自加速度計、速度傳感器或位移探頭的信號，并執行濾波、整形、測量與診斷等操作。
二、產品型號說明
產品名稱：RLC16-V111 印刷電路板
訂貨號（P/N）：200-570-101-015
制造商：Vibro-Meter（屬于 Meggitt Group）
模塊系列：RLC16 系列（Relay Logic Card）
版本號：V111（表示該印刷電路板的硬件修訂版本）
三、核心功能與技術特點
| 功能項目 | 描述 |
|---|---|
| 信號處理 | 可接收最多 16 通道的輸入信號（通常為振動或位置傳感器信號） |
| 邏輯控制功能 | 提供可編程的報警/跳閘邏輯功能，用于機器狀態響應 |
| 繼電器輸出 | 配有可配置的繼電器輸出，用于報警信號或系統聯鎖 |
| 狀態指示 | 提供 LED 指示器顯示當前通道狀態或故障報警 |
| 系統集成 | 可與 VM600 系列其他模塊配合工作，如 MPC4、IOC4T、CPUM 等 |
| 自診斷功能 | 具備故障檢測、模塊運行監控、自診斷能力 |
| 配置方式 | 通過系統軟件或機架跳線設置模塊參數 |
| 熱插拔支持 | 安裝于標準 Vibro-Meter 機架中，支持帶電更換（Hot Swap） |
英文資料：
1、 Product Overview
Vibro Meter 200-570-101-015 RLC16-V111 is an RLC16 series printed circuit board (PCB) used for machine condition monitoring and vibration protection systems. It is commonly used in vibration measurement, alarm, and protection systems for industrial rotating equipment, and is a functional module in the Vibro Meter VM600 series or similar platforms.
This board card processes signals from accelerometers, velocity sensors, or displacement probes through multiple channels and performs filtering, shaping, measurement, and diagnostic operations.
2、 Product Model Description
Product Name: RLC16-V111 Printed Circuit Board
Order number (P/N): 200-570-101-015
Manufacturer: Vibro Meter (belonging to Meggitt Group)
Module series: RLC16 series (Relay Logic Card)
Version number: V111 (indicating the hardware revision version of the printed circuit board)
3、 Core functions and technical features
Functional project description
Signal processing can receive up to 16 channels of input signals (usually vibration or position sensor signals)
The logic control function provides programmable alarm/trip logic function for machine status response
The relay output is equipped with configurable relay outputs for alarm signals or system interlocking
Status indication provides LED indicators to display the current channel status or fault alarm
System integration can work in conjunction with other modules in the VM600 series, such as MPC4, IOC4T, CPUM, etc
Self diagnostic function with fault detection, module operation monitoring, and self diagnostic capabilities
The configuration method is to set module parameters through system software or rack jumpers
Hot swappable supports installation in standard Vibro Meter racks and supports live replacement (Hot Swap)
