ABB 1MRK000614-ABr02控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
產品名稱：ABB 1MRK000614-ABr02 控制板
類型：控制板 / 控制邏輯單元
制造商：ABB
應用設備：ABB 繼電保護與自動化系統（如 REL、RET、REF 系列）
一、產品功能概述
控制邏輯執行單元
用于執行設備內部預設的邏輯判斷、動作命令、跳閘/閉鎖策略等。
信號采集與處理
對電流、電壓、頻率等模擬量或開關量進行實時采樣和分析。
與其他功能板通信交互
與電源板、通信板、人機界面板等其他模塊協同工作，實現完整控制流程。
數據監控與狀態反饋
監測設備運行狀態，輸出告警、事件、動作記錄信息至系統平臺或 SCADA。
二、典型應用領域
數字化繼電保護裝置
應用于 ABB 的繼電保護系列（如 REL670、REF615、RET670 等）中，是關鍵控制模塊之一。
變電站自動化系統
安裝于110kV~500kV 等高壓變電站中的控制屏、保護屏中，用于電網保護與切換控制。
發電廠與配電系統
支持發電設備與母線系統的保護與狀態切換邏輯控制。
SCADA 與遠動系統接口
與通信模塊聯動，實現遠程監控、控制命令的本地響應。
三、產品技術特性（典型）
高速微處理器邏輯控制
多路信號輸入輸出支持
支持電磁兼容（EMC）標準，適應嚴苛電力環境
插拔式模塊結構，便于維修更換
支持通信協議如 IEC 61850、Modbus、DNP3 等（視主設備配置）
英文資料：
Product Name: ABB 1MRK000614-ABr02 Control Board
Type: Control Board/Control Logic Unit
Manufacturer: ABB
Application equipment: ABB relay protection and automation systems (such as REL, RET, REF series)
1、 Product Function Overview
Control logic execution unit
Used to execute preset logic judgments, action commands, trip/lockout strategies, etc. within the device.
Signal acquisition and processing
Real time sampling and analysis of analog or switch quantities such as current, voltage, frequency, etc.
Communicate and interact with other functional boards
Collaborate with other modules such as power board, communication board, human-machine interface panel, etc. to achieve a complete control process.
Data monitoring and status feedback
Monitor the operating status of the equipment, output alarm, event, and action record information to the system platform or SCADA.
2、 Typical application areas
Digital relay protection device
Applied in ABB's relay protection series (such as REL670, REF615, RET670, etc.), it is one of the key control modules.
Substation automation system
Installed in control and protection screens of high-voltage substations ranging from 110kV to 500kV, used for power grid protection and switching control.
Power plants and distribution systems
Support the protection and status switching logic control of power generation equipment and busbar systems.
SCADA and Remote Control System Interface
Integrate with the communication module to achieve local response to remote monitoring and control commands.
3、 Product Technical Characteristics (Typical)
High speed microprocessor logic control
Multi channel signal input and output support
Supports electromagnetic compatibility (EMC) standards and adapts to harsh power environments
Plug in module structure for easy maintenance and replacement
Support communication protocols such as IEC 61850, Modbus, DNP3, etc. (depending on the configuration of the main device)
