GE RS-FS-9001 火焰探測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
RS-FS-9001 是一款用于檢測燃燒狀態的高性能火焰探測器，可識別多種火焰類型，包括燃氣、燃油或其他可燃介質燃燒產生的火焰信號。其設計旨在在極端環境下也能保持高度靈敏、穩定和抗干擾的火焰識別能力。
二、核心功能
火焰信號檢測
檢測火焰中紅外（IR）或紫外（UV）波段的輻射信號
支持單波段或多波段探測技術，以增強識別準確性
燃燒確認與監測
用于燃燒器點火確認、燃燒持續狀態監控
可輸出開關量或模擬量信號供上位系統使用
自診斷功能
具備光學通道污染監測、窗口結垢檢測等功能
系統自檢反饋異常狀態至控制系統
抗干擾設計
可有效抑制焊接弧光、陽光、照明燈等誤報警
內部算法優化背景噪聲屏蔽
三、技術參數（典型值，具體以數據手冊為準）
| 項目 | 參數示例 |
|---|---|
| 探測方式 | 紫外、紅外或紫外+紅外復合檢測 |
| 響應時間 | 小于 100ms |
| 電源要求 | 24V DC（常見工業電源） |
| 輸出信號 | 繼電器接點、4–20mA 模擬量、Modbus（部分型號） |
| 使用環境溫度 | -20°C 到 +70°C |
| 安裝接口 | 通用法蘭或螺紋安裝，適配多種安裝平臺 |
| 防護等級 | IP65 或更高（適用于室外或惡劣環境） |
英文資料：
1、 Product Overview
RS-FS-90001 is a high-performance flame detector used to detect combustion status, which can recognize multiple types of flames, including flame signals generated by the combustion of gas, fuel, or other combustible media. Its design aims to maintain highly sensitive, stable, and anti-interference flame recognition capabilities even in extreme environments.
2、 Core functions
Flame signal detection
Detecting radiation signals in the infrared (IR) or ultraviolet (UV) bands of flames
Support single band or multi band detection technology to enhance recognition accuracy
Combustion confirmation and monitoring
Used for burner ignition confirmation and continuous combustion status monitoring
Can output switch or analog signals for use by the upper system
self-diagnosis
Equipped with functions such as optical channel pollution monitoring and window scaling detection
System self-test feedback abnormal status to control system
anti-interference design
Can effectively suppress false alarms caused by welding arc light, sunlight, lighting fixtures, etc
Internal algorithm optimization for background noise shielding
3、 Technical parameters (typical values, please refer to the data manual for details)
Example of project parameters
Detection methods include ultraviolet, infrared, or a combination of ultraviolet and infrared detection
Response time less than 100ms
Power requirement 24V DC (common industrial power supply)
Output signal relay contacts, 4-20mA analog, Modbus (some models)
Operating environment temperature: -20 ° C to+70 ° C
Universal flange or threaded installation interface, compatible with multiple installation platforms
Protection level IP65 or higher (suitable for outdoor or harsh environments)
2.產 品 展 示
