UNIOP ETOP11-0050 顯示器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
UniOP eTOP11-0050 顯示器簡介及應用領域
一、產品概述
UniOP eTOP11-0050 是 Exor 公司推出的一款工業級觸摸屏人機界面（HMI），配有 5.6 英寸 STN 彩色液晶顯示屏，支持電阻式觸摸操作。該設備結構緊湊、功能可靠，適用于多種工業環境。
主要技術參數：
顯示屏尺寸：5.6 英寸
分辨率：320×240 像素（1/4 VGA）
觸摸屏類型：電阻式觸摸屏
電源輸入：24V DC
安裝方式：面板嵌入式安裝
通信接口：可選串口、以太網、CAN、Profibus 等擴展模塊
編程軟件：支持 UniOP Designer 或 JMobile Studio
存儲容量：標準支持約32MB用戶程序空間
狀態：該型號為早期型號，目前已停產，市場上以庫存或替代型號為主
二、典型應用領域
工業設備控制界面
應用于各類機械設備如注塑機、切割機、包裝機、數控機床等，作為人機交互平臺，顯示運行狀態、報警信息并進行參數設置。生產線自動化系統
在裝配線、流水線、檢測系統中用于數據監控和操作控制，提升自動化效率。能源與環保設備監控
應用于供水、鍋爐、風機、泵站等系統中，實現數據可視化和報警功能。樓宇自動化系統
用于中央空調、照明控制、電梯管理等子系統，提供直觀的圖形界面供用戶操作。電力與配電監控
應用于配電柜、變電站、UPS 系統中，便于遠程監控和數據采集。過程控制行業
涉及食品、制藥、化工等行業的溫度、流量、配方等參數控制與記錄。教育與實驗平臺
因體積小巧、功能實用，適合用于教學和控制系統模擬實驗環境。
英文資料：
Introduction and Application Fields of UniOP eTOP11-0050 Monitor
1、 Product Overview
UniOP eTOP11-0050 is an industrial grade touch screen human-machine interface (HMI) launched by Exor, equipped with a 5.6-inch STN color LCD display screen and supporting resistive touch operation. The device has a compact structure, reliable functions, and is suitable for various industrial environments.
Main technical parameters:
Display screen size: 5.6 inches
Resolution: 320 × 240 pixels (1/4 VGA)
Touch screen type: resistive touch screen
Power input: 24V DC
Installation method: panel embedded installation
Communication interface: optional expansion modules such as serial port, Ethernet, CAN, Profibus, etc
Programming software: supports UniOP Designer or JMobile Studio
Storage capacity: Standard supports approximately 32MB of user program space
Status: This model is an early model that has been discontinued and is mainly available in stock or as a substitute model in the market
2、 Typical application areas
Industrial equipment control interface
Applied to various mechanical equipment such as injection molding machines, cutting machines, packaging machines, CNC machine tools, etc., as a human-machine interaction platform, it displays operating status, alarm information, and performs parameter settings.
Production line automation system
Used for data monitoring and operation control in assembly lines, assembly lines, and inspection systems to improve automation efficiency.
Monitoring of Energy and Environmental Protection Equipment
Applied in water supply, boiler, fan, pump station and other systems to achieve data visualization and alarm functions.
Building Automation System
Used for subsystems such as central air conditioning, lighting control, elevator management, etc., providing intuitive graphical interfaces for users to operate.
Electricity and distribution monitoring
Applied in distribution cabinets, substations, and UPS systems, it facilitates remote monitoring and data collection.
Process control industry
Control and record parameters such as temperature, flow rate, and formula related to industries such as food, pharmaceuticals, and chemicals.
Education and Experimental Platform
Due to its compact size and practical functions, it is suitable for use in teaching and control system simulation experimental environments.
2.產 品 展 示
