UNIOP ETOR504U3P1操作面板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
UniOP ETOP504U3P1 操作面板簡介
一、產品概述
ETOP504U3P1 是 UniOP eTOP 系列的一款工業級人機界面（HMI）操作面板，配備 4.3 英寸彩色寬屏顯示器，支持電阻式觸摸功能，適用于多種自動化應用場景。
二、主要技術參數
顯示屏尺寸：4.3 英寸 TFT 彩色液晶
分辨率：480 × 272 像素（16:9 寬屏）
觸控方式：電阻式觸摸屏
內存：128MB Flash，256MB RAM
通信接口：RS-232、RS-422/485、雙以太網接口、USB 主從口、SD 卡插槽
電源輸入：24V DC
安裝方式：面板嵌入式
軟件支持：兼容 JMobile Studio 平臺，支持圖形化界面設計、宏命令、報警、趨勢、配方、多語言支持等功能
三、典型應用領域
工業自動化設備控制
用于機械設備、人機界面顯示、參數調整和報警信息監控。樓宇與能源管理系統
應用于空調、電梯、水泵等系統操作界面。過程監控與數據管理
提供歷史數據記錄、趨勢分析、配方切換等功能，便于操作與追溯。替代舊型號與維修用途
用作早期 eTOP 小尺寸面板的替代，適合舊設備升級與維護。
英文資料：
Introduction to UniOP ETOP504U3P1 Operation Panel
1、 Product Overview
ETOP504U3P1 is an industrial grade human-machine interface (HMI) control panel in the UniOP eTOP series, equipped with a 4.3-inch color widescreen display, supporting resistive touch function, and suitable for various automation application scenarios.
2、 Main technical parameters
Display screen size: 4.3-inch TFT color LCD
Resolution: 480 × 272 pixels (16:9 widescreen)
Touch mode: resistive touch screen
Memory: 128MB Flash, 256MB RAM
Communication interface: RS-232, RS-422/485, dual Ethernet interface, USB master-slave port, SD card slot
Power input: 24V DC
Installation method: panel embedded
Software support: compatible with JMobile Studio platform, supporting graphical interface design, macro commands, alarms, trends, formulas, multilingual support and other functions
3、 Typical application areas
Industrial automation equipment control
Used for mechanical equipment, human-machine interface display, parameter adjustment, and alarm information monitoring.
Building and Energy Management System
Applied to the operation interface of systems such as air conditioning, elevators, and water pumps.
Process monitoring and data management
Provide functions such as historical data recording, trend analysis, and formula switching for easy operation and traceability.
Replace old models and repair purposes
Used as a replacement for early eTOP small-sized panels, suitable for upgrading and maintaining old devices.
2.產 品 展 示
